James Hardie Weatherboard Cladding

Verified by manufacturer 6 months ago

Plank

Taylor Maxwell Variant:
Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

High-performance cladding panels and weatherboard planks.

Jump to:
0203 794 9377 Website

Application

The planks are satisfactory to be used as an exterior non-loadbearing wall cladding over timber-framed, masonry or concrete, or aluminium steel-framed walls.

Description

This range of high-performance cladding panels and weatherboard planks are a low maintenance alternative to natural wood. Manufactured from high quality portland cement, sand and cellulose fibres, weatherboard cladding boards are a lightweight, easy-to-cut material that does not shrink or split. When installed in accordance with the product's BBA certificate, and subjected to normal conditions of exposure and use, the product will have an estimated service life in excess of 30 years.


This range offers multiple colour and texture options, with a full range of colour matched or complementary coloured trims and accessories.


Features and benefits:

  • A2-s1, d0 classification in accordance with EN 13501-1: 2007.
  • Classified as Class 0 or ‘low risk’ as defined in the various national Building Regulations (see section 7 of BBA certificate 04/4147).
  • Available in two textures (a timber effect look and a smooth finish) and a variety of colours to suit a range of project designs.
  • This system utilizes ColourPlus™ Technology, which provides a multi-coat, durable and fade-resistant finish that lasts.
  • Colours range from traditional and neutral whites, greys and browns to more vibrant blues, greens and red.
  • Installation of this system is quick and easy and offers the installer maximum flexibility, with options to install boards horizontally, vertically, ship-lapped or open jointed.
  • Panels are 8 mm thick, 1220 mm wide and come in either 2400 mm or 3050 mm lengths.
  • The weight of the panels is 8.6 kg or 11.2 kg.
  • Planks are 8 mm thick, 180 mm wide and 3600 mm long.
  • The weight of the planks is 7.4 kg per plank, totaling 11.419 kg/m².
  • Portland cement boards, satisfying the requirements of Category A, Class 2 in accordance with BS EN 12467:2012.

General information

Color

Other

Finish

Smooth

Wood grain

Material

Cement

Shape

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

15 year

Uniclass

Pr_25_71_11_31 Fibre-reinforced cement weatherboardsPrimary

CAWS

H30/110 Fibre cement

H30/120 Fibre cement

H20/155 Sheet cladding (attached to timber battens)

H20/150 Sheet cladding (attached to metal support systems)

H92/120 Rainscreen cladding

H20/10 Sheet cladding

Specification data - Fibre-reinforced cement weatherboards

Standard

To BS EN 12467, category A, Class 2.

Third-party certification

UKAS-accredited third-party testing organization.

Fire rating

Fire-rated to EN 13501-1, Class A2-s1, d0.

Edges

Square.

Finished size

Guidance for specification option:

Consult manufacturer and insert requirements.

Face width

180 mm.

Thickness

8 mm.

Surface texture

Smooth.

Wood grain.

Colour

Guidance for specification option:

Consult manufacturer and insert requirements.

Length

3600 mm.

Guidance for specification option:

7.4 kg.

Sustainability data

Recyclability

100%

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

James Hardie Cladding Systems - Hardieplank - 04/4147

BBA Agrément Certificate

BBA Agrément Certificate

James Hardie Cladding Systems - Hardiepanel - 05/4248

Case studies

The Edge at Abbey Park, Colchester

The Edge at Abbey Park, Colchester

Bridgend Road, Pontyclun

Bridgend Road, Pontyclun
