Iso-Mount Type2 - Acoustic hangers for ceiling soundproofing - Soundproof Ceiling System

Verified by manufacturer 13 days ago

Oscar Acoustics Third party certifications:
  • SRL

    SRL

    Certificate type

Isolating hanger for the construction of soundproof ceilings (reduces airborne and impact noise).

Jump to:
BOS
+44 (0)1474 854902 Website

Application

Ceiling soundproofing acoustic hangers for house conversion to flats, new build and renovation of houses and flats. Shops, restaurants and other commercial soundproofing applications.

Description

Isolating acoustic hanger for the construction of soundproof ceilings (reduces airborne and impact noise).

The Iso-Mount Type2 expands the versatility of the Oscar Iso-Mount range of isolating acoustic hangers for soundproofing ceilings. It can fix under existing ceilings without disruption, directly or with extensions for 50 mm to over 1 m voids for acoustic/ thermal insulation and services.

Screw direct to concrete using one concrete screw per acoustic hanger or into plasterboard using one screw fixing into the timber joist per hanger.


Features and benefits:

  • Acoustic hanger for the ceiling soundproofing of timber joist and concrete ceilings.
  • Fixes under existing concrete and timber joist ceilings with one fixing, with associated time and cost savings.
  • Extensions available for deeper voids.
  • Improves the soundproofing of existing ceilings: impact and airborne sound reduction.
  • Acoustic hanger fixes under existing concrete and timber joist ceilings with minimum fixings.
  • All the soundproof ceiling installation is completed working only from the room below.
  • Proven acoustic performance.
  • Acoustic hanger exceeds Building Regulations Part E.
  • Requires a single hole to drill per mount; reducing installation time when drilling concrete.
  • 18 kg maximum load per mount: three mounts evenly spaced per square meter gives a maximum weight load of 54 kg/m².
  • The GL1 ‘C’ channel and GL3 connectors/ steel channels are widely available from many UK manufacturers.


Can be used in conjunction with:

  • Celbar Loosefill: Machine blown by Oscar Acoustics for larger areas or supplied compressed in bags for hand filling by the builder.
  • Oscar Seal: Acoustic intumescent acrylic sealant tested to BS EN ISO 140-3.
  • Oscar Foam: Compressible self-adhesive Class 0 foam used to isolate ceiling boards from walls.

General information

Finish

Galvanized

Material

Steel

Guidance for specification option:

Mild.

Rubber

Shape

Other

Manufacturer guidance

Exclusive patented design.

Height

50 mm

Guidance for specification option:

50 mm void - extendable.

Uniclass

Pr_20_85_32_14 Carbon steel dry lining framesPrimary

CAWS

K10/245 Ceiling lining on timber

K10/220 Proprietary suspended ceiling system

K10/25 Ceiling lining on timber

K10/50 Suspended ceiling system on metal framing

Product range

Iso-Mount acoustic hangers

Specification data - Carbon steel dry lining frames

Material

Mild steel and rubber.

Component types

-

Ceiling hangers

Acoustic ceiling mount.

Loading

18 kg (maximum).

Guidance for specification option:

Spaced evenly at 3 x Iso-Mounts per square metre the maximum loading per square metre is 54 kg.

Sound insulation

Exceeds Building Regulations (E&W) Approved Document E requirements for airborne and impact sound.

Guidance for specification option:

Copies of tests are available from Oscar Acoustics.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

Can effectively lower the carbon footprint of a building project by sequestering rich stores of carbon for the life of the structure or application.

Recyclability

66%

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1

Third party certifications

SRL

SRL

Iso-Mount Type2 Test Data - Airborne & Impact Sound Insulation of a Concrete Floor Construction
