Invicta Flow Permeable Paving

Verified by manufacturer 4 months ago

Brett Landscaping

Invicta Flow Permeable paving uses a unique combination of natural aggregates on the top surface to create a hard wearing, long lasting paving solution.

Jump to:
+44 (0)345 60 80 570 Website

Application

Domestic and commercial use: hardstanding for vehicular and pedestrian pavements including footpaths, cycle tracks, driveways, adoptable highways, commercial pavements, roof top and balcony applications.

Description

Invicta Flow Permeable paving uses a unique combination of natural aggregates on the top surface to create a hard wearing, long lasting paving solution whilst offering a stunning vibrant finish with a hint of sparkle. Invicta is available in four complementary colours a traditional plan size, making this a versatile product suitable for most projects where surface water management is required.


Features and benefits:

  • Hardstanding.
  • For vehicular and pedestrian pavements.

General information

Color

Grey

Silver

Beige

Finish

Textured

Material

Concrete

Guidance for specification option:

Precast (Agg-Tech semi-dry-pressed and vibrated).

Shape

Rectangle

Length

215 mm

Width

115 mm

Height

80 mm

Uniclass

Pr_25_93_60_17 Concrete paving blocksPrimary

CAWS

Q24/117 Permeable concrete block paving – partial infiltration

Q24/119 Permeable concrete block paving – no infiltration

Q24/115 Permeable concrete block paving – total infiltration

Q24/12 Permeable concrete block paving

Specification data - Concrete paving blocks

Standard

To BS EN 1338: 2003.

Guidance for specification option:

Design standard: BS 7533-13:2009.

Installation standard: BS 7533-3:2005 + A1:2009.

Physical properties

-

Colour

Pearl.

Onyx.

Citrine.

Moonstone.

Finish

Textured.

Profile

-

Paver type

Regular plan form.

Arrises

Chamfered, 6 x 2 mm.

Dimensions and associated tolerances

-

Nominal sizes

215 x 115 x 80 mm.

Guidance for specification option:

Unit weight: 3.68 kg.

Weathering resistance

Class 3.

Abrasion resistance

Class 3.

Guidance for specification option:

≤23 mm, determined by Wide Wheel Abrasion test.

Slip resistance

Unpolished Slip Resistance Value (USRV): ≥55; Potential for slip: Low.

Skid resistance

No requirement.

Recycled content (minimum)

None permitted.

Permeability

To BS DD 229:1996, 4265 mm/h.

Reaction to fire

Class A1.

Guidance for specification option:

When used for internal flooring.

Strength

Characteristic tensile splitting strength: ≥3.6 MPa; Failing load: ≥250 N/mm.

ThermalConductivity

1.2 W/m·K.

Tolerances on plan dimension and thickness nominal

Thickness: ±3 mm; Plan size: ±2 mm.
