INVI NoHa Invisible NoHa Sliding Door Handles - Concealed Door Handle
Verified by manufacturer 4 days ago
Concealed door handle.
Application
Concealed door handle for sliding doors.
Description
The No-Ha 2.0 Slide is a door handle that recedes into the door panel and can be used on all sliding doors that slide into the wall or in front of it. The handle is operable on both sides with plenty of space for the fingers The handle has the same look as the No-Ha 2.0 for revolving doors.
The No-Ha cover plate is not part of the mechanism so that it can be made to match the finish of the door panel. The No-Ha a cover plate is available as an accessory in MDF and in brushed stainless steel.
The milling in the door panel is the same as with the No-Ha 2.0 revolving doors. An extra piece must be fitted on the top of sliding doors that slide into the wall so that the door can be drawn out of the wall.
General information
Color | Silver Manufacturer guidanceCover plate colour. |
Material | Medium density fibreboard (MDF) Stainless steel Manufacturer guidanceCover plate material. |
Shape | Rectangle |
Width | 45 mm |
Height | 87 mm |
Uniclass | |
CAWS | P21/42 Pull handles P21/641 Pull handles |
Specification data - Pull handles
Form | NS205 (+43 mm). Guidance for specification option: Handle two sides for Sliding Doors. NS210 (+48 mm). Guidance for specification option: Handle two sides for Sliding Doors. NS200 (+38 mm). Guidance for specification option: Handle two sides for Sliding Doors. NS105 (+38 mm). Guidance for specification option: Handle one side for Sliding Doors. |
Diameter | N/A. |
Material and finish | MDF. Stainless steel. Manufacturer guidanceCover plate material. |
Colour | Silver. |
Mounting | Recedes into the door panel. |
Sustainability data
Material | Medium density fibreboard (MDF) Stainless steel Manufacturer guidanceCover plate material. |
Literature
INVI-NoHa Invisible Sliding Door Handles
