Internal GRP Cleanroom Windows - 30 Min Fire Rating

Verified by manufacturer 3 months ago

Dortek Ltd

A glass-reinforced polyester window and frame unit.

Jump to:
+44 (0)1482 226848 Website

Application

Suitable for the following applications:

  • Healthcare.
  • Pharmaceutical.
  • Food.
  • Cleanrooms.
  • Leisure.

Description

A glass-reinforced polyester window and frame unit with enhanced cleaning capabilities suitable for cleanrooms.


Features and benefits:


  • Specifically designed for healthcare, pharmaceutical and cleanroom environments, Dortek windows are double or multiple glazed with an ultra-clean flush surface.
  • Fire-rated hygienic internal window with glass-reinforced polyester (GRP) frames.
  • Dortek hygienic fire windows are specially constructed to offer superior quality and to reinforce hygiene in all environments where infection control is critical. Manufactured to suit both traditionally built and modular wall systems, the Dortek cleanroom window complies with GMP/ GLP requirements.
  • Windows are mounted into the wall system to provide a flush surface without ledges or joints. Insulated glass units or multiple glazing can be easily incorporated into most designs. Available with smartglass technology, blinds and laser protection.
  • Fully flush, ultra-clean hygienic construction.
  • Comprehensive fire, laser and radiation protection.
  • Available with integral blinds and smartglass.
  • Hygienic glass-reinforced polyester (GRP) frames.
  • Fire resistant for up to four hours.

General information

Finish

Smooth

Material

Glass Reinforced Plastic (GRP)

Shape

Square

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_98_15 Composite window unitsPrimary

CAWS

L10/33 Proprietary windows

L10/390 Proprietary windows

Product range

Windows

Specification data - Composite window units

Dimensions and configurations

-

Manufacturer guidance

Insert requirements.

Minimum: 400 x 400 mm.

Maximum (F60): 1203 x 1403 mm.

Maximum (F120): 1590 x 1340 mm.

Consult manufacturer for further details.

Product performance

-

Fire performance

-

Fire resistance

60 minutes.

120 minutes.

240 minutes.

Frame

-

Profile

Two piece with factory joints mitred and polished; 25 mm thick.

Plastics finishes

-

Manufacturer guidance

Consult manufacturer and insert colour requirement.

Glazing or infill

-

Requirements

Triple glazed.

Guidance for specification option:

With 6 mm-thick clear toughened glass flush to both sides of wall and 5 mm-thick clear Firelite centre pane.

Fixing features

Concealed fixing arrangement.

Accessories

None.

Integral blinds.

Lead lining.

Smartglass.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Ireland

Guidance for specification option:

Or Sweden

BIM objects

Platform Compatible Version
Revit
-

1

Literature

9.9.2. Dortek Hygienic Windows Data Sheet

9.9.2. Dortek Hygienic Windows Data Sheet
