Application

  • Specifically designed for the structural repair of concrete structures such as runways, bridges, decks and floors, which cannot be taken out of service for prolonged periods.
  • This product can be used for repairs up to 100 mm deep as supplied. For deeper repairs of up to 300 mm, Intercrete 4802 can be combined with a non-porous aggregate of particle size 6–10 mm (e.g. granite) to form a pourable concrete.
  • Depending upon the condition of the substrate and any exposed steel reinforcement, additional surface preparation products from the Intercrete range may be required prior to the application of Intercrete 4802.
  • The following topcoats are recommended for Intercrete 4801: Intercrete 4850 and Intercrete 4870.
  • Consult International Protective Coatings for further details.

Description

Features and benefits:

  • Curing at low temperatures.
  • Compatibility with concrete.
  • Consistent strength development.
  • Grey, matt finish.
  • Compressive strength to BS EN 4551 at 20°C: 60 MPa (after 28 days).


General information

Color

Grey

Finish

Matt

Material

Cement

Guidance for specification option:

Fibre reinforced, fast setting cement based repair mortar.

Uniclass

Pr_20_31_53_15 Concrete repair mortarsPrimary

CAWS

C41/530 Proprietary mortar repairs

C41/610 Mortar repair of cracks

C42/310 Repair mortar

Specification data - Concrete repair mortars

Standard

To BS EN 1504-3.

Mortar type

Cement based.

Product Reference

Intercrete® 4802

Dry film thickness

5–100 mm.

Density

2150 kg/m³.

CompressiveStrength

60 MPa.

Guidance for specification option:

To BS EN 4551 at 20°C: After 28 days.

  • 1 hour: 10 MPa.
  • 2 hours: 20 MPa.
  • 4 hours: 30 MPa.
  • 1 day: 40 MPa.
  • 7 days: 50 MPa.

Flexural strength

10.5 MPa.

Guidance for specification option:

To BS EN 4551 at 20°C: after 28 days.

Weight

25 kg.
