Imperial Grand Bioclimatic Pergola

Imperial Grand Bioclimatic Pergola

Able Canopies Ltd

The Imperial Grand Bioclimatic Pergola features roof slats that can be opened and closed and has a maximum size of 6 m x 4.5 m - multiple structures can be installed together to cover larger areas.

Jump to:
+44 (0)800 389 9072 www.ablecanopies.co.uk
Description

Wall mounted/ free-standing aluminium canopy with remotely controlled roof slats, providing ultimate shade and shelter versatility, allowing the adaption of the structure to suit changeable weather conditions and provide the optimum environment. When the sun is at its hottest, the roof slats can be closed to create 100% UV protection underneath or they can be opened at a slight angle to allow a cooling breeze through the canopy. The roof slats can also be closed to block any rain or snowfall, keeping the area underneath dry, sheltered and comfortable.

LED lighting and fabric screens can be included, along with glass side panels to provide extra weather protection and an enclosed feel to the structure.

General information

WarrantyDescription

10 years for the frame (3 years for the mechanisms)

Uniclass 2015

Pr_20_65_78_58 Open sided sheltersPrimary

CAWS

B91/330 Canopy

Specification data - Open sided shelters

Product Reference

Imperial Grand Bioclimatic Pergola

Size

-

Projection

Insert requirement, available 7 m.

Length

Insert requirement, available 7 m.

Height

Insert requirement.

Roof slats

190 x 30 mm

195 x 38 mm

196 x 38 mm

Colour

-

Roof slats

RAL 9010 Pure White

RAL 7016 Anthracite Grey

RAL 9005 Jet Black

RAL 9006 White Aluminium

RAL 7037 Dusty Grey

RAL 8028 Terra Brown

RAL 1019 Grey Beige

Special order

Insert requirement.

Frame

RAL 9010 Pure White

RAL 7016 Anthracite Grey

RAL 9005 Jet Black

RAL 9006 White Aluminium

RAL 7037 Dusty Grey

RAL 8028 Terra Brown

RAL 1019 Grey Beige

Special order

Insert requirement.

Accessories

None

Fabric side panels

Glass side panels

LED lighting

Standard product features

Roof panels:

Covered with aluminium roof slats that can be opened and closed with the use of a supplied remote control.

Framework:

  • Main frame: Constructed from UNI 6060 and UNI 6063 aluminium.
  • Posts: 160 x 160 mm.
  • Roof profile: Aluminium slats

Finish:

Polyester powder coated.

Guttering:

Supplied with an integrated guttering system that disperses water down the canopy posts.

Weather resistance:

The canopy is constructed from aluminium which is naturally rust and rot resistant and is well known for its high resistance to weathering. When the roof slats are closed, the canopy offers 100% UV protection from the sun.

Load resistance:

The Imperial has been tested for wind and snow loadings and the results vary for each canopy size.

Guarantee:

Supplied with up to a ten year guarantee.

Digital objects
Platform Compatible Version Certified to
IFC
-

4

2.1
Revit
-

4

2.1
Download now from NBS National BIM Library
