Ideal Standard Tempo Cube IFP+ 180 x 80 cm Double-Ended Bath

Verified by manufacturer 3 months ago

Ideal Standard (UK) Ltd

A rectangular bath tub 1800 x 800 mm with no tapholes.

Jump to:
+44 (0)870 122 8822 Website

Application

Suitable for domestic and hotel applications.

Description

Double-ended, Tempo bath with gently sloping interior offers ample space for two. Constructed from Idealform Plus+ for exceptional strength and rigidity.


Features and benefits:

  • Domestic and hotel use.
  • Increased strength and rigidity.
  • Supplied no taphole for maximum flexibility.
  • Also available in Idealform.

General information

Color

White

Material

Acrylic

Guidance for specification option:

Idealform Plus+.

Shape

Rectangle

Length

1795 mm

Width

795 mm

Height

475 mm

Warranty description

25 year

Uniclass

Pr_40_20_06_08 BathsPrimary

CAWS

N13/35 Baths

N13/355 Baths

Specification data - Baths

Form

Rectangular.

Standards

To BS EN 14516.

Materials

Idealform Plus+.

Colour

White.

Size

1795 x 795 x 510 mm.

Manufacturer guidance

Length x width x height.

Volume to overflow (maximum)

248.0 L.

Water supply, overflow and waste holes

-

Water supply

No tap holes.

Waste

Bottom waste outlet.

Integral accessories

Not required.

Thermostatic Valve - A5901.

Guidance for specification option:

TMV thermostatic mixing valve, 22 mm.

Brassware - B0730.

Guidance for specification option:

Tempo 2 hole bath filler.

Bath Waste - E1486.

Guidance for specification option:

Luxury bath pop-up waste and overflow.

Bath Front Panel - E2606.

Guidance for specification option:

Tempo Cube 180 cm bath front panel.

Bath End Panel - E2607.

Guidance for specification option:

Tempo Cube 80cm end panel.

Trap - S8970.

Guidance for specification option:

Trap 1½" plastic P with 75 mm seal, multi-purpose outlet suitable for plastic and BS copper pipe.

Brassware - B0731.

Guidance for specification option:

Tempo 2 hole bath shower mixer.

Brassware - B0732.

Guidance for specification option:

Tempo 1 hole bath filler.

Brassware - B0733.

Guidance for specification option:

Tempo 1 hole bath shower mixer.

Bath Waste - S8830.

Guidance for specification option:

Waste 1½" bath chain and overflow, plastic plug.

Weight

37.00 kg.

Sustainability data

Contains Red List materials

No

Material

Acrylic

Guidance for specification option:

Idealform Plus+.

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Bathroom Collections brochure

Bathroom Collections brochure
