Hydropave Shannon Duo | Permeable Block Paving
Verified by manufacturer 21 days ago
EPD
Certificate type
Smooth paving block. Two sizes in one pack.
Application
For residential and commercial applications when used in conjunction with the correct sub-base design, in accordance with the latest British standard.
Description
Designed specifically to provide a random bond finish, the smooth surface on Hydropave Shannon Duo block paving makes it ideal for shopping centres, schools, superstores, public paths and street schemes.
Features and benefits:
- Has frost protection.
- BREEAM rating A (A+ can be achieved when used with recycled sub-base).
General information
Color | Other Guidance for specification option:
|
Finish | Smooth |
Material | Concrete |
Length | 208 mm 173 mm |
Width | 173 mm |
Height | 60 mm |
Uniclass | |
CAWS | Q1/322 Concrete block pavers Q24/12 Permeable concrete block paving Q24/119 Permeable concrete block paving – no infiltration Q24/117 Permeable concrete block paving – partial infiltration Q24/115 Permeable concrete block paving – total infiltration |
Product range |
Specification data - Concrete paving blocks
Classification data | |
Standard | To BS EN 1338. Manufacturer guidanceInstalled to BS 7533-3. |
Physical properties | |
Colour | Bracken. Charcoal. Heather. Slate. |
Finish | Smooth. |
Dimensions and associated tolerances | |
Nominal sizes | 208 x 173 x 60 mm. 173 x 173 x 60 mm. |
Weathering resistance | Class 3. Guidance for specification option: ≤1.0 kg/m² as a mean with no individual value >1.5 kg/m². |
Abrasion resistance | Class 3. Guidance for specification option: Wide Wheel Abrasion Test: ≤23 mm. |
Slip resistance | Extremely low (>75 USRV). |
Environmental performance requirements | |
Recycled content (minimum) | Not less than 12%. |
Efflorescence | Minimum 12 hour vapour curing to significantly reduce the possibility of efflorescence. |
Drainage void width | 5% to accommodate correct grit grading, reduced maintenance and maximise drainage flow rate. |
Permeability | 29 000 L/s/ha. |
Strength | >3.6 MPa. |
BREEAM rating | A (A+ can be achieved when used with recycled sub-base). |
Surface finish | Hard wearing surface layer with a minimum layer of 4 mm and >350 kg/m³ cement. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Concrete |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Certified | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 13.82 Lower emissions | |
Recyclability | 100 |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer guidanceNot less than 12% |
Product certifications
Product certifications
EPD
Environmental Product Declaration (EPD) Artro 80mm, Hydropave Pedesta 60mm, Hydropave Pedesta 80mm, Hydropave Shannon 60mm, Marker Block 80mm, Pedesta 50mm, Pedesta 60mm, Pedesta 80mm, Shannon 50mm, Shannon 60mm, Toberloc 80mm
Literature
Hydropave - Environmentally friendly Permeable paving
