Hydropave Mayfair Flags
Application

Suitable for all pedestrian areas and traffic-free zones, with some sizes suitable for occasional vehicular overrun. Always refer to BS 7533-8: 2003 for guidance on the correct flag.

Description

Concrete paving flag with a granite appearance manufactured to BS EN 1339.

Features and benefits:

  • Functions as a SuDS paving system.
  • Superb hard-wearing smooth surface.
  • Vibrant long-lasting colours.
  • Significantly reduced efflorescence.
  • Manufactured with sparkling natural granite (>57%) aggregates.
  • BREEAM rating: A. ('A+' rating can be achieved by using a recycled sub-base).

Application:

Suitable for all pedestrian areas and traffic-free zones, with some sizes suitable for occasional vehicular overrun. Always refer to BS 7533-8: 2003 for guidance on the correct flag.

General information

Finish

Hard-wearing surface layer with a minimum layer of 4 mm and >390 kg/m³ cement

Features

Functions as a SuDS paving system

Material

Concrete

Shape

Square

Uniclass 2015

Pr_25_93_60_16 Concrete flagsPrimary

CAWS

Q25/315 Concrete flags

Specification data - Concrete flags Enhanced data

Product Reference

Hydropave Mayfair Flags

Standard

Manufactured to BS EN 1339

Physical properties

-

PhysicalPropertiesColour

Graphite

Mid Grey

Silver

PhysicalPropertiesFinish

Hard-wearing surface layer with a minimum layer of 4 mm and >390 kg/m³ cement

Nominal sizes

400 x 400 x 65 mm

Slip resistance

Extremely low (>75 USRV)

Skid resistance

Extremely low (>75 USRV)

BendingStrength

>3.5 MPa

Drainage void width

2.7% to accommodate correct grit grading and reduced maintenance and maximize drainage flow rate

Frost protection

Yes

Permeability

15 000 L/ s/ ha

EnergyUsed

100%

WaterUsed

100%

Manufacturing location

Produced in the UK with locally sourced materials

Design life

25 years

CarbonFootprint

0.0

Standard product features

Features:

Functions as a SuDS paving system.

Finish:

Hard-wearing surface layer with a minimum layer of 4 mm and >390 kg/m³ cement.

Material:

Concrete.

Shape:

Square.

Recycled Content

Not less than 12%.

Recyclability:

100%.

Country of Origin:

United Kingdom.

Environmental information

Recyclability

100%

Recycled content

Not less than 12%
