Hydrolock 2

Application

For the waterproofing of new structures. Can be used externally on concrete to provide an effective barrier to the transmission of water.

Description

Mechanically bonded geosynthetic clay liner (GCL) composite of pulverized bentonite embedded between two layers of geotextile with an LLDPE membrane fixed to one side.


Features and benefits:

  • The internal 5 kg of natural sodium bentonite swells in contact with water to form a low permeability waterproofing barrier, with the membrane forming an impermeable barrier.
  • Satisfactory for use as a fully bonded Type A waterproofing protection.

General information

Material

Bentonite

Pulverised bentonite embedded between two layers of geotextile with an LLDPE membrane.

Polyethylene

Clay

Uniclass 2015

Pr_15_57_27_39 Geosynthetic clay liners (GCLs)Primary

CAWS

J40/285 Loose laid bentonite damp proofing/ tanking

J40/20 Loose laid plastics or rubber sheet damp proofing

J44/120 Geosynthetic clay lining (GCL)

J40/120 Loose laid plastics or rubber sheet damp proofing

J40/297 Waterproofing/ Damp proofing membrane

Specification data - Geosynthetic clay liners (GCLs) Enhanced data

Integral accessories

Sodium bentonite jointing strips.

Product Reference

Hydrolock 2

Thickness

7.5 mm.

Environmental information

Country of material origin

United Kingdom
