HV-STYLVENT | Wall / Window Extract Fan Series

Name: HV-STYLVENT | Wall / Window Extract Fan Series
Brand: S&P UK Ventilation Systems Ltd
SKU: awr4pMZXQ1RvVXYMZeH6Ap

Verified by manufacturer 5 months ago

HV-150 A E

S&P UK Ventilation Systems Ltd

Axial flow fans for wall or window mounting applications.

Jump to:

BOS

+44 (0)1473 276890 Website

Application

Suitable for a wide range of general residential, commercial and industrial exhaust or supply ventilation applications.

Description

Complete range of axial flow fans for wall or window mounting applications. All the fans are supplied with tough ABS plastic grilles, shutter and single phase 230V-50Hz motor. All the fans are class II insulation and IPX4 rated. The HV-STYLVENT series comprises of 3 diameters: 150, 230 and 300 mm, including several operating options.

Features and benefits:

Includes a shutter.
Natural ventilation position.
Single-phase motor 230V-50Hz with thermal overload protection.
Single speed operation.
Class II insulation.
Model 230 and 300 are reversible with CR-150 control accessory.
Automatic, thermally actuated shutter.

General information

Color	White
Material	Plastic
Warranty description	Two year

Uniclass	Pr_65_67_29_05 Axial flow fansPrimary Pr_65_67_29_23 Domestic fan units
CAWS	U90/413 Ventilation fan units U90/413 Ventilation fan units

Specification data - Axial flow fans

Duty	-
Air volume	Up to 300 l/s.
Fan speed	2350 rpm.
Accessories	REB-1R. Guidance for specification option: Speed controller including a switch to reverse the airflow direction. Only to be used with models HV-230 AE, HV-300 AE. Threaded rod set. Guidance for specification option: Threaded rods and sleeves for use when installing the HV fans on walls from 25 mm up to 300 mm thick.
