Hush FR Roofing Membrane - Acoustic Roof Membrane

Verified by manufacturer 2 days ago

Hush Acoustics

Acoustic rubber roofing membrane.

Jump to:
+44 (0)114 551 8683 Website

Application

Noise issues inside buildings resulting from poor acoustic performance of the roof can be resolved using the Hush FR Roofing Membrane

Principally designed as an additional acoustic layer for lightweight flat roof systems, the product’s performance capabilities mean it may also provide an effective solution for other types of roofs too, including metal systems such as standing seam.

Excellent acoustic performance is achieved through Hush FR’s composition of recycled rubber crumb bonded with polyurethane to form a 10mm membrane, which greatly increases mass in the roof construction and reduces vibration caused by raindrops hitting the external roof surface.

Hush FR Roofing Membrane has been subjected to extensive testing at a UKAS accredited facility to confirm its performance in flat roof systems for both airborne and impact sound insulation. In all the tests conducted, an improvement in the acoustic performance of the roof construction was recorded compared to designs that did not feature the membrane, with some of the performance levels being significantly higher.

This product is ideally suited to educational and health sector buildings where indoor acoustic comfort is of particular importance.

Description

Rubber roofing membrane for use in flat roof constructions to reduce airborne and impact noise.

General information

Color

Black

Beige

Finish

Other

Material

Rubber

Polyurethane

Manufacturer guidance

Recycled rubber crumb bonded with polyurethane.

Shape

Rectangle

Length

6000 mm

Guidance for specification option:

Roll length.

Width

1250 mm

Guidance for specification option:

Roll width.

Height

10 mm

Uniclass

Pr_25_57_06_71 Resilient layer insulationPrimary

CAWS

J41/10 Reinforced bitumen membrane warm deck roof covering

J41/430 Warm deck roof insulation

J42/10 Warm deck roof covering

J42/430 Warm deck roof insulation

SKU Code

FR

Product range

Acoustic Roofing

Specification data - Resilient layer insulation

Classification data

Material

Recycled rubber crumb bonded with polyurethane.

Density

770 kg/m³ (approximate).

Thickness

10 mm.

Fire performance

To BS EN 13501-1: Efl.

Roll length

6 m.

Roll width

1.25 m.

Colour:

Black/ beige.

TensileStrength

To DIN EN ISO 1798: 0.8 N/mm².

Elongation at break

To DIN EN ISO 1798: 125%.

Service temperature

-30 to +80°C.

Sustainability data

Country of product manufacture

United Kingdom

Material

Rubber
Polyurethane

Manufacturer guidance

Recycled rubber crumb bonded with polyurethane.
