HUKP-0101-62 - Straight Lever Handle 148 mm - 22 mm Ø Straight 4 mm rose SSS - Door handle
Verified by manufacturer 13 days ago
Lever handle on rose.
Application
Suitable for commercial heavy duty applications .
Description
A stainless steel lever handle on rose.
Features and benefits:
- 22 mm Ø designer lever handle in solid bar stainless steel.
- Square elbow 15 x 15 mm.
- Concealed bush fixing rose.
- Un-sprung, for use with heavy duty followers.
- 52 mm Ø and 4 mm thick rose, 38 mm c.c. for bolt through fixings.
- To suit door thickness from 35–54 mm.
- Manufactured to BS EN1906: 2012 Class code: 4/7/-/1/1/4/0/U.
- 316L Grade Stainless Steel for use in corrosive environments.
- Suitable for high frequency of use.
- EN1634-1:2000 suitable for use on fire resisting doors.
General information
Color | Silver Black Guidance for specification option:
Bronze Guidance for specification option:
Other Guidance for specification option: Brass. Manufacturer guidanceRAL colours available. Consult manufacturer and insert requirements. |
Finish | Satin Polished Matt Manufacturer guidanceOther finishes available to special order. Consult manufacturer. |
Material | Stainless steel Bronze Brass |
Length | 148 mm |
Width | 22 mm Guidance for specification option: Diameter. |
Warranty description | 25 year Guidance for specification option: Performance guarantee. |
Uniclass |
Product range |
Specification data - Door lever handle sets
Standard | To BS EN 1906. |
Classification grades (minimum) | |
Category of use | 3. |
Durability | 7. |
Fire resistance | 1. |
Safety | 1. |
Corrosion resistance | 4. |
Security | 0. |
Type of operation | U. |
Size | 22 mm diameter. |
Material and finish | Satin stainless steel, grade 316L.Polished stainless steel, grade 316L.Matt.Mid bronze.Dark bronze.Polished brass.Satin brass.Manufacturer guidanceOther finishes available to special order. Consult manufacturer and insert requirements. |
Colour | Silver.Matt black.Mid bronze.Dark bronze.Hafele black.Brass.RAL.Guidance for specification option: Consult manufacturer and insert requirements. |
Mounting | Concealed bush fixing rose. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
1. Häfele Architectural Ironmongery Brochure
