Horizon Seat
Verified by manufacturer 4 months ago
ZNF 6
ZNF 6
Contemporary steel and timber seat.
Application
Suitable for rural and urban settings.
Description
Steel and timber seat designed with flat seat and backrest profiles to suit contemporary settings. Available in a wide range of sizes and configurations, designed to accommodate three to four people.
Features and benefits:
- Supplied as separate platform and post sub-assemblies which are securely and discretely bolted together, allowing seat platforms to be removed for any routine maintenance works that can be more readily carried out off-site, or replaced if damaged, without the need for costly ground works.
- The platform profiles and the alignment of the support posts are common to both the seat and bench, meaning they can be placed side-by-side to form a continuous line of variable form seating.
- Takes up less space than separated independent seats, provides different types of seating to suit the needs of different user groups, as well as make a more interesting visual appearance than identical seating throughout.
General information
Color | Grey Silver Brown Other Guidance for specification option: Polyester powder coated to any RAL colour. |
Finish | Smooth Satin Bright Powder-coated |
Material | Stainless steel Steel Timber |
Shape | Rectangle |
Length | 1890 mm 2490 mm |
Width | 540 mm |
Height | 820 mm |
Warranty description | One year |
Uniclass | |
CAWS | Q50/225 Seats Q50/30 Street furniture |
Product range |
Specification data - Street and site seats
Length | 1.89 m. |
Base | Root fixed.Guidance for specification option: Standard. Bolt down. |
Material | Standard: Steel frame and iroko timber slats. |
Finish as delivered | Standard: Galvanized frame and smooth planed slats. |
Colours | RAL.Guidance for specification option: Polyester powder coated to any RAL colour. |
Slats | Iroko timber, smooth planed finish. Guidance for specification option: Standard. Iroko timber, UV protective finish. Wood plastic composite (WPC). |
Frame | Stainless steel, grade 1.4301 (304), bright polished. Stainless steel, grade 1.4301 (304), satin polished. Stainless steel, grade 1.4401 (316), bright polished. Stainless steel, grade 1.4401 (316), satin polished. Steel, galvanized finish. Guidance for specification option: Standard. |
Armrests | Not required. A – Two ends. AC – Two ends and two centres. ACM – Two ends, two centres and one mid arm. Guidance for specification option: For four-person seats only. AM – Two ends and one mid arm. Guidance for specification option: For four-person seats only. |
Anti-skate device | Not required. Required. |
Width | 540 mm. |
Height: | Height, above ground: 820 mm, Height, below ground: 350 mm. |
Form | Three-person seat with front-to-back slats. |
SeatingHeight | 450 mm. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
