Hinged Doorset - Uniguard
Application

Suitable for a wide range of applications on commercial and industrial buildings.

Description

A hinged steel doorset, which comprises a robust and durable, low-maintenance, general-purpose door and frame.


The steel door and frame offer higher security than timber counterparts, enhanced by the strength of the standard hinges employed. Computer technology ensures that both door and frame are accurately punched and reinforced for all hardware.


Features and benefits:

  • Door arrangements: doors can be supplied as singles, pairs, leaf and a half, and with or without side and transom panels.
  • Door leaves: 1.2 mm-thick zinc-coated galvanized steel sheets, stiffened internally with honeycomb material and reinforced for hardware. The overall panel thickness is 43 mm and there are no face seams. Horizontal channels are welded to the inside of the sheets to close off the top and bottom of the leaf.
  • Frame: manufactured from 1.5 mm zinc-coated galvanized steel and formed into a single rebate profile. Supplied in knock-down form for ease of handling/ installation. The frames are morticed, reinforced, drilled and tapped for hinges and strike plates. An overlapping steel astragal is fitted on a pair to ensure positive sealing.
  • Hardware: various items of hardware can be supplied/ accommodated. As standard, stainless steel ball bearing hinges are included.

General information

Size

Finish

Polyester powder-coated

Optional. Consult manufacturer for details and insert requirements.

Primed

Standard.

Color

A range of BS/ RAL colours available

-

Material

Steel

Zinc-coated galvanized steel

Shape

Rectangular

WarrantyDescription

12 months

Uniclass 2015

Pr_30_59_24_52 Metal doorsetsPrimary
Ss_25_30_20_39 Hinged doorset systems
Pr_30_59_24_37 High-security doorsets

CAWS

L20/480 Doorsets

L20/55 Doorsets

Specification data - Metal doorsets Enhanced data

Frame

-

Material

Steel.

1.5 mm zinc-coated galvanized steel formed into a single rebate profile.

Door leaf

-

Thickness

43 mm.

Accessories

Fixed transom panel, glass.

Fixed transom panel, steel.

Flush bolts to the inactive leaf of pairs.

Lever handles.

Locks/ latches.

Consult manufacturer for details and insert requirements.

Louvres, size (w x h): 450 x 1500 mm.

Louvres, size (w x h): 450 x 300 mm.

Mortice lock/ latch.

One and a half pairs of stainless steel hinges per leaf.

Overhead hydraulic closer.

Fitted with a leaf selector on pairs of doors if both leaves active.

Panic latches/ bolts.

Removable transom panel, glass.

Removable transom panel, steel.

Vision panel, circular.

Insert requirements.

Vision panel, square.

Insert requirements.

Vison panel, rectangular.

Insert requirements.

Product Reference

Hinged Doorset - Uniguard

Size

Arrangement

Double door (pairs).

Available up to 2.9 x 2.9 m.

Leaf and a half with side and transom panels.

Leaf and a half without side and transom panels.

Single door.

Available up to 1.45 x 2.9 m.

Finish

Polyester powder-coated

Optional. Consult manufacturer for details and insert requirements.

Primed

Standard.
