Hempafire Pro 315 Fast Dry - Intumescent Coating Fire Protection (Solvent Based) - Intumescent Coating Solvent Based

Verified by manufacturer 2 months ago

Hempel A/S Third party certifications:
  • EPD

    EPD

    Certificate type

A one component, solvent-borne, intumescent coating, optimized for 60 minutes for protection of structural steel against cellulosic fires.

Jump to:
+447827 448651 Website

Application

1. As passive fire protection for structural steel in interior and exterior conditions (Up to C4 conditions ISO 12944-2). Suitable for open profile beams and columns, cellular beams and hollow section beams and columns.


2. As a repair and touch up coating for damaged areas of freshly applied Hempafire Pro 315 Fast Dry.

Description

To Specify a full Intumescent Fire Protection Coating System C1-C4 (Primer + Intumescent + Topcoat) click on the link below and add to your Chorus Specification:

Intumescent Fire Protection Coating Systems (C1–C4) - C1–C4 Corrosivity & Fire Protection | Hempel A/S | NBS Source (thenbs.com)


To Specify a full Anti-Corrosion System C1-C5 (No Intumescent Fire Protection) (Primer + Topcoat) click on the link below and add to your Chorus Specification :

Anti-Corrosion Protective Coating System (C1–C5) - For Corrosive Environments | Hempel A/S | NBS Source (thenbs.com)


For further advice on Specifications please contact Ian Morton at iam@hempel.com


Hempafire Pro 315 Fast Dry

A one component, solvent-borne, intumescent coating, optimized for 60 minutes for protection of structural steel against cellulosic fires.


Features and benefits:

  • Service temperature: -10°C (14°F) to 50°C (122°F).
  • It is suitable for in-shop and on-site applications.
  • Tested and approved according to EN13381-8 and BS 476-21 for up to 90 minutes fire protection.
  • CE marked product with European Technical Approval ETA nº 18/0689 according EAD 350405-00-1106.


Application method:

  • Airless spray.
  • Brush.


Certificates/Approvals:

Tested and approved according to EN 13381-8 and BS 476-21 for up to 90 minutes fire protection. CE marked product with European Technical Approval ETA nº 18/0689 according EAD 350405-00-1106. Approved for up to Type X conditions (all conditions).


Drying time:

Determined for dry film thickness 750 micron (30 mils) at standard conditions. Indicative values at 20ºC; Surface-dry: 5 minutes, Through-dry: 15 Hours.

General information

Color

White

Manufacturer guidance

10000/ White.

Finish

Matt

Material

Intumescent

Shape

Formless

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_35_31_68_43 Intumescent protective coatingsPrimary

CAWS

M61/140 On-site overcoating to existing steel

M61/170 Off-site coating to galvanized steel

M61/115 On-site coating to galvanized steel

M61/120 On-site coating to existing steel

M61/150 Off-site coating to unprimed steel

M61/110 On-site coating to primed steel

M61/160 Off-site coating to primed steel

Specification data - Intumescent protective coatings

Composition

Solvent-based.

Colour

10000/ White.

Volume solids

75% ± 3%.

Flash point

4°C (39.2°F).

Specific gravity

1.3 kg/L (11.1 lbs/US gallon).

VOC content

340 g/L (2.8 lbs/US gallon).

Shelf life

12 months, 25°C (77°F).

Manufacturer guidance

12 months 25°C/77°F , thereafter the paint quality is subject to re-inspection.

Standard

CE marked product with European Technical Approval ETA nº 18/0689 according EAD 350405-00-1106.

Sustainability data

Third party certifications

EPD

EPD

EPD - Hempafire Pro 315 Fast Dry

Literature

Hempel Corporate Brochure

Hempel Corporate Brochure

Hempel Sustainability E-Folder

Hempel Sustainability E-Folder

Frequently Used Paints Brochure

Frequently Used Paints Brochure

Sports and Leisure Facilities Brochure

Sports and Leisure Facilities Brochure

Infrastructure Brochure

Infrastructure Brochure

Amsterdam Airport Case Study

Amsterdam Airport Case Study

Vale Protective Coatings Case Study

Vale Protective Coatings Case Study

Maison de l'Ordre des Advocats Case Study

Maison de l'Ordre des Advocats Case Study

Hempafire Pro 315 Brochure

Hempafire Pro 315 Brochure

Hempafire Pro 315 and Hempafire Pro 315 fast dry Product Information Sheet

Hempafire Pro 315 and Hempafire Pro 315 fast dry Product Information Sheet

Jordal Amfi Case Study

Jordal Amfi Case Study

Cellulosic Passive Fire Protection Brochure

Cellulosic Passive Fire Protection Brochure

Civil Structures Brochure

Civil Structures Brochure

Hempafire Pro 315 Fast Dry Datasheet

Hempafire Pro 315 Fast Dry Datasheet
