Heat Mat PipeGuard
Description

Heat Mat PipeGuard is designed to prevent frozen condensate pipes in the most extreme conditions. This is a quick solution to prevent frozen, cracked and damaged pipes and ensures water keeps flowing down to -25°C. Heat is applied to the pipe when the temperature drops close to freezing, and switches off again once the pipe has reached a safe temperature.

Features:

  • Ready-made unit, simply connect to power supply.
  • Simple to install, can be quickly zip-tied in place.
  • Integrated thermostat.
  • Monitors pipe temperature (rather than air temperature) to minimize running costs.
  • Maintenance free and supplied with a ten-year warranty.
  • Fully earthed for electrical safety.

General information

Features

Ready-made unit, simply connect to power supply

Simple to install, can be quickly zip-tied in place

Integrated thermostat

Monitors pipe temperature (rather than air temperature) to minimize running costs

Maintenance free and supplied with a ten-year warranty

Fully earthed for electrical safety

Specification data

Product Reference

Heat Mat PipeGuard

Length

1.4 m

Suitable for: 10–22 mm pipes; 0.7–1.4 m long, 23–38 mm pipes; 0.7–1.2 m long.

2.0 m

Suitable for: 10–22 mm pipes; 1.5–2.0 m long, 23–38 mm pipes; 1.3–1.8 m long.

3.0 m

Suitable for: 10–22 mm pipes; 2.1–3.0 m long, 23-28 mm pipes; 1.9–2.7 m long.

4.0 m

Suitable for: 10–22 mm pipes; 2.1–4.0 m long, 23–38 mm pipes; 1.9–3.6 m long.

5.0 m

Suitable for: 10–22 mm pipes; 4.1–5.0 m long; 23–28 mm pipes; 3.7–4.5 m long.

8.0 m

Suitable for: 10–22 mm pipes; 4.1–8.0 m long, 23–38 mm pipes; 3.7–7.2 m long.

10.5 m

Suitable for: 10–22 mm pipes; 8.1–10.5 m long, 23–38 mm pipes; 7.3–9.4 m long.

14.0 m

Suitable for: 10–22 mm pipes; 10.6–14.0 m long, 23–38 mm pipes; 9.5–12.6 m long.

18.5 m

Suitable for: 10–22 mm pipes; 14.1–18.5 m long, 23–38 mm pipes; 12.7–16.7 m long.

22.5 m

Suitable for: 10–22 mm pipes; 18.6–22.5 m long, 23–38 mm pipes; 16.8m–20.2 m long.

38.0 m

Suitable for: 10–22 mm pipes; 22.6–38.0 m long, 23–38 mm pipes; 20.3–34.2 m long.

45.0 m

Suitable for: 10–22 mm pipes; 38.1–45.0 m long, 23–38 mm pipes; 34.3–40.5 m long.

Standard product features

Cable location:

For pipes up to 22 mm in diameter, the cable can be run along the base of the pipe or spiralled around it. For larger pipes the cable must be spiralled around to provide even heat coverage.

Technical properties:

  • Heating element: Dual conductor constant wattage heating wire.
  • Voltage: 230 V (±10%).
  • Output per m: 14 Watts.
  • Output range: 19–567 W.
  • Amp rating: 3 A.
  • Sensor: Integrated thermal sensor.
  • Start-up temperature: +3°C.
  • Cut out temperature: +13°C.
  • Insulation: Expanded low density polyethylene.
  • Earth protection: 100% earth shielded.
  • Earth protection: 100% earth shielded.
  • IP rating: IPX7
  • Coldtail lead: 1.35 m.

Product Options

Additional system components:

  • Boiler condensate pipes.
  • External water pipes.
  • Water pipes in lofts and outbuildings.
  • Waste pipes.
