Healthcare IPS Panel System
Application

Suitable for dry and wet bathroom environments, for installing:

  • Sinks.
  • Taps.
  • Soap/ paper towel dispensers.
  • Hand dryers.

Description

Complete integrated panel system (IPS) for washrooms, manufactured to suit project requirements.

Features and benefits:

  • Fully compliant with NHS Estate Guidelines and HTM 68 panel specifications.
  • Durable.
  • Available in panel and box configurations.
  • Helps to conceal pipework.
  • Easy to install.

Applications:

Suitable for dry and wet bathroom environments, for installing:

  • Sinks.
  • Taps.
  • Soap/ paper towel dispensers.
  • Hand dryers.

General information

Uniclass 2015

Ss_25_25_45_25 Duct and wall panel lining systemsPrimary

CAWS

K32/15 Duct/ wall lining panels

K32/160 Duct linings – preplumbed panels and proprietary frames

Specification data - Duct and wall panel lining systems

Product Reference

Healthcare IPS Panel System

Design

As drawing

As reference

Type

Boxed unit

19 mm high pressure laminate (HPL) panels mounted onto boxing.

Panel system

13 mm compact grade laminate (CGL) panels.

Overall height

3000 mm maximum. See 'Options' below and insert requirements.

Colour/ Finish

Consult manufacturer's literature and insert requirements.

Edging

Not required

For the panel system; edges are supplied with black, machine rounded profile.

2 mm polyvinyl chloride (PVC)

For boxed unit only.

Post-formed, vertical

For boxed unit only.

Standard product features

Panel width:

800 mm.

Product Options

Design:

Hinged and lockable panels are available on request - consult manufacturer for details.

Type:

- Boxed unit:

Delivers a uniform finish to the panels.

- Panel system:

Allows for the reuse of existing sanitaryware.

Overall height:

Panel build-up:

  • Bottom panel: 430 mm (standard).
  • Middle panel: 670 mm (standard).
  • Top panel: Variable, up to a finished complete height of 3000 mm (top panel can be a maximum height of 1100 mm).

Full-height or half-height panels are available - consult manufacturer for details.
