Hawa Super 500 B


Sliding hardware with bracket suspension, for use with single wooden doors with a panel weight up to 500 kg.

Features and benefits:

  • Suitable for use in low headroom applications, and with fire-retarding sliding doors.
  • Simple to install - low installation height.
  • Dual running track.
  • Vertically adjustable (±2 mm).


  • Four-wheeled trolley, M12, with steel, ball bearing wheels (standard and fire-retardant variants available).
  • Top and edge fixing bracket, with suspension plate and hanger bolt M12.
  • Spring-loaded mortise-type door stop, galvanized steel, screw-fit.
  • Floor-mounted guide, galvanized steel, groove width 5 mm.

For two-panel sliding doors, order two sets for single doors. Consult manufacturer for further details.

General information

Uniclass 2015

Pr_30_36_36_23 Door track and running gearPrimary


P21/10 Quantities and locations

P21/350 Door track and running gear

Specification data - Door track and running gear

Product Reference

Hawa Super 500 B (11655)

Running track



With flush mounting flanges

With top mounting flanges


6000 mm

Cut to size

Insert requirements.


Manufacturer's standard

Fire retardant

Accessories/ Other requirements

Not required

Cover plate for top and edge fixing bracket

Available with dull chromium or stainless steel finish; insert requirement.

Track stop, to be drilled into the track

Galvanized steel.

Standard product features


Top hung.

Product Options

Running track:

Stainless steel (hole positions vary - consult manufacturer for details).

Accessories/ Other requirements:

Spares are also available, consult manufacturer for details.
