Haven Carpet Tile Collection: Familiar 5T285
Verified by manufacturer 6 months ago
35210
35210
M1 emission classification
Certificate type
EPD
Certificate type
250 x 1000 mm carpet tile, with a polymer modified bitumen backing.
Application
Recommended installation methods (product specific):
- Monolithic; Brick; Ashlar; Herringbone; Stagger.
Description
Carpet tile with a polymer modified bitumen backing, available in 12 colours.
Features and benefits:
- Multi-level pattern loop.
- 100% solution dyed Eco Solution Q nylon fibre.
- Use classification 33 Commercial Heavy EN1307.
- Cradle to Cradle (TM) Bronze Certified and EPD available.
- 15-year commercial limited warranty.
- We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme
- Adhesive-Free Installation: IOBAC MagTabs™
General information
Color | Gold Green Blue Grey Pink |
Material | Nylon |
Shape | Rectangle |
Length | 1000 mm |
Width | 250 mm |
Height | 8 mm |
Warranty description | 15 year Guidance for specification option: Commercial limited warranty |
Uniclass | |
CAWS | M50/15 Carpet tiling M50/130 Carpet tiling |
Product range |
Specification data - Pile carpet tiles
Style | Tufted 1/10", 39.4 per 100 mm. |
Material | Eco Solution Q® Polyamide 6. |
Classification | |
Standard | To BS EN 1307. |
Third-party certification | Cradle to Cradle: Bronze. Indoor air quality: A+ and Environmental product declaration. |
Level of use class | To BS EN 1307, class 33. |
Luxury rating class | LC1. |
Recycled content | 25% (eco solution q® polyamide 6). |
Size | 250 x 1000 mm. |
Colour and pattern | Golden. |
Dye method | 100% solution dyed. |
Primary backing | Pet non-woven. |
Secondary backing | Taskworx®tile (polymer modified bitumen). |
Total thickness | 8 mm. |
Mass | 949 g/m² (nominal total pile mass). |
Pile density | To ISO 85430, 126 g/cm³. |
Dimensional stability | To EN 986, ≤0.2%. |
Sound insulation | To ISO 10140, 26 dB. |
Sound absorption | To ISO 354/116540, 10 αw/Class E. |
Thermal resistance | 0.086 m² K/W. |
Colour fastness | >6. |
FlammabilityRating | To EN 13501-1, Bfl-S1 (adhered testing). |
Castor chair rating | To EN 985, ≥2.4. |
Light reflectance | 29.7. |
Sustainability data
Country of product manufacture | United Kingdom |
Recyclability | Guidance for specification option: re[TURN] TakeBack scheme. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25 % Guidance for specification option: Eco Solution Q® Polyamide 6 |
Third party certifications
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
M1 emission classification
M1 Certificate
EPD
Shaw Contract Shaw Europe EPD
