Harmony - Acoustic Panel

Verified by manufacturer 2 days ago

Soundtect Third party certifications:
  • Green Tag

    Green Tag

    Certificate type

  • Independent sustainability assessment

    Independent sustainability assessment

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

  • VOC Content test Certificate

    VOC Content test Certificate

    Certificate type

Slatted acoustic wall and ceiling covering

Jump to:
BOS
+44 (0)203 0402939 Website

Application

Acoustic Wall and ceiling applications:

  • office
  • break out areas
  • restaurants
  • lecture hall
  • education
  • gymnasium
  • public area
  • lecture hall
  • auditoriums
  • home cinema
  • meeting room
  • hospitality
  • swimming pool area
  • spa
  • medical centre
  • airport
  • library
  • hotel
  • reception area
  • atrium
  • dining hall
  • assembly hall
  • classroom
  • sales showrooms

Description

Pre-cut Freestyle battens are prefixed to our super absorbent Freestyle felt backing with 10 mm spacing which is super fine allowing easy installation on curved and straight surfaces alike.

Harmony acoustic panels are available in 24 colours as well as our popular printed wood effect finishes for that wood slatted panel look.

Soundtect manufacture Global Greentag certified sustainable acoustic solutions, using up to 70% recycled materials.

Our acoustic panels offer finely tuned reverberation and sound control.

Features and benefits of Harmony acoustic wall and ceiling covering:

  • standard battens are 25 mm width x 20 mm depth but any size possible on request.
  • Elevated design potential.
  • Incredible versatility.
  • Available in any configuration from the 24 Freestyle colour and six Timba wood-effect range of options.
  • Each acoustic panel is a maximum 2400 x 1200 mm but bespoke sizes available, including bespoke size slats and spacing.
  • Acoustic panels are installed on the walls or ceiling to create a harmonious finish with superb sound control properties.
  • Excellent sound absorption.
  • Finely tuned reverberation thanks to Soundtect’s pioneering acoustic technology.
  • Environmentally friendly and recyclable, Freestyle™ Acoustic Panels are suitable for projects when there is an eco-conscious consideration to be made.
  • Manufactured by Soundtect®.
  • Independently certified.
  • Acoustic solutions for use on walls and ceilings.
  • Composition: 100% polyester.
  • Low VOC.
  • Colorfastness to Light, AATCC16(3), Class 4.5.
  • ISO 14006 certified manufacturing facility.
  • Certified 100% recyclable.
  • Recycled content: Up to 70% (minimum 50%) post consumer recycled materials.

10-12 weeks sea shipment

2-3 air freight

General information

Color

Beige

Black

Blue

Brown

Green

Show more

Material

Polyester fibre (PET)

Shape

Rectangle

Square

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Pr_35_93_13_80 Sound attenuator infill unitsPrimary
Ss_25_25_75_05 Acoustic panel lining systems

CAWS

K13/170 Acoustic panel lining

K13/170 Acoustic panel lining

K40/20 Board-suspended ceiling systems

K40/135 Board-suspended ceiling system

Specification data - Sound attenuator infill units

Form

Panel.

Raft.

Application

Ceiling mounting.

Wall mounting.

Material

Polyester.

Material density

10 mm, 2 kg/m².

20 mm, 4 kg/m².

Acoustic performance

-

Sound absorption

NRC 0.75 (20 mm).

Fire performance

-

Reaction to fire

To EN 13501, Bs1,d0.

Dimensions

-

Size (length x width)

2400 x 600 mm.

Thickness (overall)

25 mm.

Profile

Linear.

Surface pattern

Solid.

Colour

Ballet.

Bolero.

Calypso.

Chacha.

Conga.

Contemporary.

Disco.

Flamenco.

Hiphop.

Jive.

Lambada.

Latin.

Mambo.

Passo.

Polka.

Quickstep.

Rumba.

Salsa.

Tango.

Twist.

Vogue.

Waltz.

Zumba.

Ebony.

White oak.

Pine.

Oak.

Walnut.

Chestnut.

MoistureContent

Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture.

Colour fastness

Colourfastness to Light, AATCC16(3), Class 4.5.

Sustainability data

Contains Red List materials

No

Country of material origin

China

Country of product manufacture

Hong Kong

Material

Polyester fibre (PET)

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

70 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Third party certifications

Green Tag

Green Tag

GreenTag GreenRate Level B

Independent sustainability assessment

Independent sustainability assessment

Global Green Tag

QA Certificate

QA Certificate

Health declaration 221007_SOU_Freestyle & 3D panel_PhD_Certificate_v2

QA Certificate

QA Certificate

ST air quality VOC test report GZHL1907031817OT

VOC Content test Certificate

VOC Content test Certificate

VOC CONTENT

Literature

Harmony specification sheet

Harmony specification sheet

Freestyle Care and Maintenance

Freestyle Care and Maintenance

Freestyle installation guide

Freestyle installation guide

Freestyle Manufacture Warranty

Freestyle Manufacture Warranty

Freestyle Specification Sheet

Freestyle Specification Sheet

Freestyle warranty

Freestyle warranty

Global Green Tag certification

Global Green Tag certification

Harmony Specification Sheet

Harmony Specification Sheet

Soundtect Brochure 2023

Soundtect Brochure 2023

Voc Content

Voc Content

Harmony Installation Instructions

Harmony Installation Instructions
