Handrail - Oval
Verified by manufacturer 4 days ago
Oval PVC-U handrail sleeve over continuous aluminium core. 45 mm nominal diameter, HBN 00-04 - handrail guidance, HBN 00-09 - infection control.
Application
Suitable for corridors, ramps, interior stairs and entrances in public buildings, education, healthcare, leisure, and retail environments.
Description
Oval PVC-U handrail sleeve over continuous aluminium core.
The 45 mm diameter Oval Handrail is fitted on stainless steel underslung brackets fixed directly to the wall substrate.
Features and benefits:
- Easy to hold.
- Available in a range of colours to suit dementia colour considerations as well as contrasting accessories to mark wall ends or changes in direction for those with partial sight assisting with DDA requirements.
- Warm to the touch.
General information
Color | Grey Blue White Silver |
Finish | Textured Guidance for specification option: Stippled. |
Material | PVC-U Aluminium |
Shape | Oval |
Length | 3500 mm |
Width | 45 mm |
Height | Bespoke |
Uniclass | |
CAWS | L30/70 Proprietary handrails L30/580 Proprietary handrails |
Specification data - Handrail systems
Handrails | Aluminium handrail with PVC-U sleeve. |
Fixing to parent structure | Stainless steel underslung brackets. |
Dimensions | 3500 mm long; 45 mm diameter. Guidance for specification option: L x W. |
Colour | Graphite RAL 7036 (nearest); LRV: 21. Royal Blue RAL 5017; LRV: 11. White RAL 9016; LRV: 86. Dark Grey RAL 7015; LRV: 12. Mid Grey BS 00 A 05; LRV: 37. |
External finish | PVC-U: stippled. |
Accessories | Guidance for specification option: An accompanying range of accessories is available, including contrast options designed to assist service users with impaired vision or dementia. Consult manufacturer for details and insert requirements, or omit. |
Fire performance | To BS EN 13823. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | PVC-U Aluminium |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
