Description

Electric hand dryers.

General information
Uniclass 2015
Hand dryers (Pr_40_70_62_37)Primary
Specification data - Hand dryers
Product Reference

0302005 WAD 5 warm air dryer

0302019 Warm air dryer

0302047 Elite recessed warm air dryer

0302520 Slimline warm air dryer

0302533 Automatic warm air hand dryer

White.

0302534 Jet, high speed automatic air dryer

White.

0302535 Automatic warm air hand dryer

Silver.

0302536 Jet, high speed automatic air dryer

Silver.

Product Options

Product reference:

– 0302005 WAD 5 warm air dryer:

  • Standard: To BS EN 60335-2-23.
  • Material: High strength, die cast aluminium, finished in gloss stove enamelled paint.
  • Colour: White
  • Size (h x w x d): 270 x 335 x 195 mm.
  • Weight: 6.4 kg.
  • Operating voltage: 220–240 V, 50/60 Hz.
  • Current consumption: 2.8 kW at 240 V.
  • Motor: 110 volt.
  • Power consumption: 11 A at 240 volts (2.6 kW).
  • Sound Level: 76 dBA at 1 m from air outlet.
  • Operation: Infrared, fully automatic, no touch.
  • Usage detail: Holding down the deflector diverts 70% for face drying. Deflector returns to hand drying position on release.
  • Fixing: Includes fixings for hard wall installation.

– 0302019 Warm air dryer:

  • Standard: To BS EN 60335-2-23.
  • Material: Easy clean brushed stainless steel.
  • Size (h x w x d): 280 x 270 x 148 mm.
  • Weight: 2.79 kg.
  • Operating voltage: 220–240 V, 50/60Hz.
  • Current consumption: 2.0 kW at 240 V.
  • Insulation: Class 1.
  • Fuse rating: 13 A.
  • Motor speed: 2700 rpm.
  • Sound level: 65 dBA at 1 m from air outlet.
  • Operation: Infrared, fully automatic, no touch.
  • Drying time: 30 seconds.
  • Usage detail: Ideally suited for applications where hygiene is of paramount importance, such as food preparation areas, hospitals and clinics.
  • Fixing: Includes fixings for hard wall installation.

– 0302047 Elite, recessed warm air dryer:

  • Standard: To BS EN 60335-2-23.
  • Materials: Brushed stainless steel.
  • Size (h x w x d): 346 x 382 x 186 mm.
  • Recess Size (h x w x d): 322 x 357 x 171 mm.
  • Weight: 8.8 kg.
  • Current: 13 A.
  • Heater power rating: 2.2– 2.65kW (11 A).
  • Sound level: 76 dBA at 1 m from air outlet.
  • Motor speed: 4650 rpm.
  • Operation: Fully automatic.
  • Fixing: Includes fixing kit for panel installations 12–40 mm thick.
  • Can be combined with Elite paper towel dispenser and waste bin.

– 0302520 Slimline warm air dryer:

  • Standard: To BS EN 60335-2-23.
  • Material: Powder coated steel.
  • Colour: Light grey.
  • Size (h x w x d): 345 x 350 x 100 mm.
  • Weight: 5.4 kg.
  • Operating voltage: 220–240 V, 50/60 Hz.
  • Current consumption: 7.8 A at 240 V.
  • Nominal output: 1.9 kW at 240 V.
  • Power Rating: 900 W.
  • Sound Level: 71 dBA at 1 m from air outlet.
  • Air Speed: 28 m/s (130 m³/h).
  • Drying time: 17 seconds.
  • Air outlet temperature: 54°C at 20°C ambient temperature.
  • Operation: Infrared, fully automatic, no touch.
  • Fixing: Includes fixings for hard wall installation.

– 0302533 Automatic warm air warm air dryer (white)/ 0302535 (silver):

  • Standard: To BS EN 60335-2-23.
  • Material: Die cast aluminium.
  • Size (h x w x d): 300 x 280 x 175 mm.
  • Weight: 4.5 kg.
  • Operating voltage: 220–240 V, 50 Hz.
  • Heater element: 250 W, thermal protected.
  • Power rating: 900 Watts.
  • Sound level: 70 dBA at 1 m from air outlet.
  • Air speed: 90 m/s (200 m³/h).
  • Operation: Infrared, fully automatic and self adjusting.
  • Drying time: 10 seconds.
  • Timing protection: 60 seconds to auto shut off.
  • Fixing: Includes fixings for hard wall installation.

– 0302534 Jet high speed automatic warm air dryer (white)/ 0302536 (silver):

  • Standard: To BS EN 60335-2-23.
  • Cover: ABS (Acrylonitrile Butadiene Styrene).
  • Size (h x w x d): 650 x 292 x 250 mm.
  • Weight: 11.0 kg.
  • Operating voltage: 220–240V 50Hz.
  • Power rating: 850 W.
  • Sound level: 70 dBA at 1 m from air outlet.
  • Air speed: 86 m/s (150 m³/h).
  • Operation: Infrared fully automatic and self adjusting.
  • Display: LCD instruction with 18 second countdown.
  • Drying time: 6–10 seconds.
  • Timing protection: 30 seconds to auto shut off.
  • Fixing: Includes fixings for hard wall installation.
