Halsey Taylor HTHBHVR8-NF - Drinking fountain packages

Third party certifications:
  • QA Certificate

    Certificate type

MIW Water Cooler Experts

Outdoor, Vandal Resistant, Refrigerated, Wall Mounted, Combination Drinking Fountain & Bottle Filling Station - WRAS Approved.

Jump to:
+44 (0)1207 572 000 www.miw.co.uk

Vandal resistant bottle filler and drinking fountain, for wall mounting. Non-filtered and refrigerated, for indoor or outdoor use.

Features and benefits:

  • Vandal-resistant construction with self-closing push buttons which control water flow, and stainless steel casing to ensure minimal damage.
  • Suitable for high volume indoor and outdoor settings such as schools, playgrounds and courtyards due to sturdy frame and a recessed orifice which prevents the cross-contamination of germs.
  • Features both a drinking fountain and HydroBoost® bottle filling station.
  • Automatic stream height regulator included, which maintains a consistent level of flow under water pressures from 20 to 105 psi.
  • Green Counter™ visual panel will display the number of plastic bottles saved from landfill by being refilled.
  • An in-line strainer will trap any dirt or dust particles larger than 0.14 mm before they reach the waterway.
  • Incorporates laminar flow to prevent chugging or spitting and to create a clean, easy fill.
  • Quick flow rate of 1.1–1.5 gallons of water per minute.
  • Chilling capacity of up to 30 litres per hour.
  • Chrome plated, vandal-resistant, one-piece bubbler tap included.
  • Real drain system eliminates standing water.
  • Comes with an advanced pressure cooler system, which is fully insulated with EPS foam to meet UL requirements for self-extinguishing material.
  • Low maintenance as the unit is hermetically sealed and features lifetime lubrication.
  • Satin finish resists both water marks and fingerprints.
  • Meets with the requirements of the Americans with Disabilities Act (ADA) and the Equality Act 2010.
  • WRAS and BREEAM approved, and GreenSpec® listed.
  • Manufacturer provides a five-year limited warranty on any refrigeration systems; one-year warranty on electrical components and water system.
  • Meets the requirements of the Safe Drinking Water Act.

General information



ADA Approved, BREEAM Approved, GreenSpec Listed, NSF 61/372 lead free, Outdoor Rated, Refrigerated, Stainless Steel, Vandal Resistant, WRAS Approved


Stainless steel




473 x 457 x 986 mm


5 Year Limited Warranty on the refrigeration system of the unit. Electrical components and water system are warranted for 12 months from date of installation.

Uniclass 2015
Pr_40_70_15_96 Water coolersPrimary
Specification data - Water coolers
Product Reference

Halsey Taylor HTHBHVR8-NF


Not required


WaterSentry® Plus filter kit (bottle fillers).


Cane apron for HAC, HVR, EMABF and VRC models.


In-wall carrier (single).

Standard product features

Size (h x w x d):

985 x 470 x 470 mm.


38.5 kg.


Stainless steel.




Wall mounted. Wall security brackets included.

Water temperature:



32 mm (1 1/4").

Rated power input:

370 W.

Nominal voltage:

230 V (50 Hz).

Digital objects
PlatformCompatibleVersionCertified to
Revit 2016 2 2.0
- 2 2.0
Download now from NBS National BIM Library
Third party certifications
  • WQA: Certificate: NSF/ANSI 61 and 372
  • WRAS: Certificate: 1707084
  • UL: Certificate: 399
  • CAN/ CSA: Certificate: 22.2 No. 120
