H-BAU FIBERNOX® V-ROD GFRP REINFORCEMENT SYSTEM
Verified by manufacturer 3 months ago
GFRP concrete reinforcement system.
Application
FIBERNOX® V-ROD is an effective alternative to stainless steel or galvanically treated reinforcing steel.
Description
A GFRP concrete reinforcement system available in a range of bar diameters. It is made of environmentally sustainable fibre reinforced material which has high corrosion and alkali resistance, combined with high tensile strength and with low weight. Available in wide range of bent shapes and lengths, it is also non-magnetic, non-conductive and has thermal insulating properties. H-BAU FIBERNOX® V-ROD is an effective alternative to stainless steel or galvanized reinforcing steel.
Features and benefits:
- Glass fibre-reinforced plastic with a resin core.
- E-Modulus >60 GPa, guaranteed tensile strength >1000 MPa.
- Sand impregnated surface for a stronger bond.
- Straight, helical or bent rods.
- Certified by CAN CSA S807-10 in Canada.
- Long-term corrosion- and alkali-resistant.
- High tensile strength combined with a low weight.
- Non-conductive, non-magnetic.
- Stable, long-life material providing a very good concrete bond.
- Easily cut on site or by tunnel boring machines (TBM).
General information
Color | Green |
Finish | Coarse |
Material | Glass Reinforced Plastic (GRP) |
Shape | Other Guidance for specification option: Available in the form of straight or bent rods. |
Length | Bespoke |
Width | Manufacturer guidanceAvailable in 6mm - 32mm diameter bars |
Height | Manufacturer guidanceAvailable in 6mm - 32mm diameter bars |
Uniclass | |
CAWS | E30/240 Proprietary prefabricated reinforcement |
Specification data - Fibre-reinforced plastics bar reinforcement
Standard | Certified by CAN CSA S807-10 in Canada. |
Reinforcement material | Fibre-reinforced plastic consisting of fibreglass strands with a resin core. |
Shape code | V-ROD RODS. |
Diameter | 6 mm.8 mm.10 mm.12 mm.14 mm.16 mm.18 mm.20 mm.22 mm.25 mm.32 mm. |
Fire resistance | 120 minutes. |
Length | 11.9 m. |
Sustainability data
Country of product manufacture | Canada |
Literature
Fibernox GFRP Reinforcement
