GRS Glass Railing System - Taper-Loc Base Shoe for Frameless Glass Balustrade System for Laminated Glass
Description

Aluminium and stainless steel glass railing system.

Features:

  • Comprises aluminium base rail and stainless steel railing, with glass fittings.
  • A range of attachment methods to the substrate has been developed – contact manufacturer for details.
  • Custom cutting and mitring service available.
  • Designed for use with laminated glass.

General information

Features

Comprises aluminium base rail and stainless steel railing, with glass fittings

A range of attachment methods to the substrate has been developed – contact manufacturer for details

Custom cutting and mitring service available

Designed for use with laminated glass

Uniclass 2015

Ss_25_60_05_05 Balustrade and guarding systemsPrimary

CAWS

L30/30 Proprietary

L30/560 Proprietary balustrades

Specification data - Balustrade and guarding systems

Product Reference

GRS Glass Railing System - Taper-Loc Base Shoe for Frameless Glass Balustrade System for Laminated Glass

Base shoe

L56S10D

Surface-mounted.

L56S10F

Side-mounted.

Standard product features

Base shoe:

  • Standard square aluminium base shoe channel for glass railing systems. Pre-drilled.
  • Size (h x w): 120.6 x 73 mm.
  • Length: 3050 mm.
  • Glass thickness suitability: 13.52 mm.
  • Finish: Mill.

LTL96X Taper-Loc™ Taper Set:

  • Construction: Made up of four reinforced nylon tapers and one L-pressure block.
  • Glass thickness suitability: 13.52 mm.

TLK12 Installation/ Removal Tool:

Designed for tightening the Taper-Loc™ Taper Set in the channel of the base shoe.

EUGR20BS Premium Cap Railing:

  • Diameter: 48.3 mm.
  • Standard length: 3000 mm.
  • Finish: Brushed stainless steel grade 1.4401 (316).

Glass suitability:

Laminated (requires TAPER-LOC laminated tapers only).
