Groundgrid Flush - Ground Reinforcement Block
Verified by manufacturer 7 days ago
Super-strong and eco-friendly interlocking grid system for various applications. Manufactured from 100% recycled plastic, with flush base.
Application
Suitable for use on:
- Construction sites;
- Green car parking areas;
- Private lanes and access roads;
- Pathways and drives;
- Golf courses;
- Landscapes;
- Equestrian and livestock facilities;
- Green roof and rooftop gardens;
- River and road embankments;
- Private airfields.
Description
Super-strong and eco-friendly interlocking grid system for various applications. Manufactured from 100% recycled plastic, with flush base.
Features and benefits:
- Highest quality recycled plastic.
- Heavy duty and lightweight design.
- Quick and easy to assemble.
- East to install, reducing on site costs.
- Lightweight.
- Proven connection system.
- Surface reinforcement with natural drainage.
- Minimal maintenance.
- Non-slip and crack-proof.
- Weatherproof and environmentally friendly.
- Frost and UV resistant.
- Dimensionally stable.
- Prevents gravel migration.
- Sustainable.
- Non expanding.
- 100% recyclable.
General information
Color | Black |
Finish | Smooth |
Material | Polypropylene Polyethylene |
Shape | Rectangle Guidance for specification option: Plan shape. |
Length | 570 mm Guidance for specification option: Per unit (plan size). |
Width | 380 mm Guidance for specification option: Per unit (plan size). |
Height | 40 mm |
Uniclass | |
CAWS | Q25/350 Plastics pavers Q30/361 Reinforced grass system Q25/185 Gravel-filled plastics paving system Q25/62 Plastics pavers |
Specification data - Plastics cellular pavers
Supplied by | Principal Building Products Ltd. |
Physical properties | |
Material | Recycled plastics. Guidance for specification option: Polypropylene/ polyethylene. |
Colour | Black. |
Top surface finish | Plain. |
Profile | |
Paver type | Regular plan form, rectangular. |
Interlocking features | Interlocking |
Dimensions | |
Plan size | 570 x 380 mm. |
Thickness (minimum) | 40 mm. Guidance for specification option: Wall thickness: 6 mm. |
Load-carrying capacity (minimum) | Maximum 400 tonne/m². Guidance for specification option: Axle load: 120 kN. |
Environmental performance requirements | |
Recycled content (minimum) | 100%. |
Weight | 1.0 kg per unit. |
Sustainability data
Material | Polypropylene Polyethylene |
Recyclability | 100%. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Literature
Flush Groundgrid datasheet
