Gorillo Hand Dryer

Verified by manufacturer 4 months ago

Gorillo Junior Jet Hand Dryer

Heat Outdoors & Handy Dryers Variant:

Range of blade hand dryers.

Jump to:
BOS
+ (0) 1279 466 500 Website

Application

Washrooms, particularly suitable for noise-sensitive environments.

  • Pro: Particularly suited to conference facilities, performance spaces and commercial office buildings.
  • Junior: Particularly suited to schools and universities.
  • Blade: General purpose.

Description

Range of blade hand dryers.


Features and benefits:

  • Quiet hand dryers: 70 dB.
  • HEPA filter with internal UVC filter sterilizer included as standard (optional for Gorillo Blade).
  • Fast drying time of 7–10 seconds (7–9 seconds for Junior model).
  • In-built digital room thermometer: Self-adjusting air heat output.
  • Concealed waste water collection tank.


Gorillo Junior:

  • Small and compact design.
  • Low-energy option.
  • Motor speed can be switched between high and low to adjust noise and energy usage.
  • Glowing LED countdown timer and smiley face to aid younger users.

General information

Color

Silver

Guidance for specification option:

Metallic silver.

White

Black

Finish

Polished

Powder-coated

Material

PVC-U

Guidance for specification option:

White and Metallic Silver.

Shape

Rectangle

Length

172 mm

Guidance for specification option:

Junior Jet hand dryer.

220 mm

Guidance for specification option:

Blade/ Pro Blade hand dryer.

215 mm

Guidance for specification option:

Ultra Blade hand dryer.

Width

295 mm

Guidance for specification option:

Junior Jet hand dryer.

300 mm

Guidance for specification option:

Blade/ Pro Blade/ Ultra Blade hand dryer.

Height

690 mm

Guidance for specification option:

Junior Jet hand dryer.

685 mm

Guidance for specification option:

Blade/ Pro Blade hand dryer.

700 mm

Guidance for specification option:

Ultra Blade hand dryer.

Warranty description

Three year

Guidance for specification option:

Pro Blade.

Two year

Guidance for specification option:

Junior Jet; Blade.

Five year

Guidance for specification option:

Ultra.

Uniclass

Pr_40_70_62_37 Hand dryersPrimary

CAWS

N13/64 Hand dryers

N13/472 Hand dryers

Specification data - Hand dryers

Form

High-velocity air through HEPA filter.

Guidance for specification option:

  • Warm air speed output: 100 m/s.
  • Drying time: 7–9 seconds.
  • Air output temperature: 40°C (where ambient temperature below 24°C); automatically adjusted.

Operation

Automatic.

Guidance for specification option:

Infrared, self-adjusting.

Timer

Fixed.

Guidance for specification option:

60 seconds auto-shut off.

Electrical supply

-

Power rating

1.65 kW.

Guidance for specification option:

  • Motor type: 750 W.
  • Motor overload protection: Motor assembly designed with over current fuse, replaceable.
  • Heater element: 1850 W (heater on); 750 W (heater off).
  • Heater thermal protection: Auto-resetting thermostat turns unit off at 85°C (185°F); thermal fuse cut unit off at 142°C (288°F).

Rated operational voltage (Ue)

220–240 V a.c.

Frequency

50/ 60 Hz.

Body

-

Material

Manufacturer's standard.

Guidance for specification option:

Weight: 7.5 kg.

Finish

Manufacturer's standard.

Colour

Silver metallic.

White.

White with blue interior.

White with black interior.

Black.

Ingress protection (minimum)

IPX1.

Guidance for specification option:

Isolation: Class 1.

Dimensions

690 x 295 x 172 mm.

Guidance for specification option:

Height x width x depth.

Noise level at 1 m (maximum)

70 dB(A).

Features

Hands only.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Gorillo Blade Data Sheet

Gorillo Blade Data Sheet

Gorillo Blade User Manual

Gorillo Blade User Manual

Gorillo Junior Data Sheet

Gorillo Junior Data Sheet

Gorillo Junior User Manual

Gorillo Junior User Manual

Gorillo Pro Blade Data Sheet

Gorillo Pro Blade Data Sheet

Gorillo Pro Blade User Manual

Gorillo Pro Blade User Manual

Gorillo Ultra Blade Data Sheet

Gorillo Ultra Blade Data Sheet

Gorillo Ultra Blade User Manual

Gorillo Ultra Blade User Manual
