GMR Galvanized Masonry Reinforcement

Name: GMR Galvanized Masonry Reinforcement
Brand: Wincro Metal Industries Ltd
SKU: qDJm4GUitFQytKpDQqxc2R

Verified by manufacturer 5 days ago

WMR30

Galvanized mild steel wire masonry bed joint reinforcement

Jump to:

Application

Suitable for reinforcing walls 100–215 mm thick, for a number of applications including:

Galvanized mild steel wire masonry bed joint reinforcement.

Features and benefits:

UKCA marked to BS EN 845-3.
Manufactured in 2.7 m lengths.
Galvanized mild steel wire.
Available in four standard widths; 60, 100, 150 and 175 mm.
Longitudinal wires have a minimum characteristic yield strength of 500 N/mm².
Manufactured from three wire sizes and, where flattened, have an equivalent wire diameter of 3, 4 and 5 mm.
Used to improve the structural performance of masonry walls by providing additional resistance to lateral loads.
It can also be used to reduce the risk of cracking either at stress concentrations around openings or as a result of movement.

Type:

GMR Reinforcement - Single span system with a welded flat tie for use in single leaf walls.
GMRM reinforcement mesh coils - For reinforcing panels, especially over openings and lintels. Also used in foundations, parapets and sleeper walls.

Color	Silver
Finish	Galvanized Guidance for specification option: Carbon steel.
Material	Steel Guidance for specification option: Galvanised Mild Steel – (suffix product code with /G).
Shape	Other
Length	2700 mm Manufacturer guidance Standard length.
Width	60 mm 100 mm 150 mm 175 mm Manufacturer guidance Available in four standard widths.
Warranty description	25 year

Uniclass	Pr_20_96_71_10 Carbon steel bed joint reinforcementPrimary
CAWS	F30/270 Meshwork joint reinforcement F30/42 Channel/ slot ties used with partial fill insulation

SKU Code	GMR GMRM

Product range	Windposts & Reinforcement

Classification data
Standard	To BS EN 845-3.
Dimensions	-
Wire size	3 mm. Manufacturer guidance Diameter.
Ladder or truss width (overall)	60 mm. 100 mm. 150 mm. 175 mm.
Type	18/8 masonry reinforcement.
Length	2700 mm. Manufacturer guidance Standard.
Materials	Galvanised mild steel. Guidance for specification option: Suffix product code with /G.

Contains Red List materials	No
Country of product manufacture	United Kingdom
Manufacturing plant location	3 Fife St, Sheffield S9 1NJ, UK
Material	Steel Guidance for specification option: Galvanised Mild Steel – (suffix product code with /G).
Recyclability	Stainless steel is fully recyclable
