Glass Skylight F100 Circular - rooflight

Name: Glass Skylight F100 Circular - rooflight
Brand: Lamilux Rooflights Ltd
SKU: pspqHb7auet6qXTqQz5NKB

Verified by manufacturer 9 days ago

F100GC-SX-F: Fixed (non opening)

Lamilux Rooflights Ltd

Third party certifications:

TUV - Safety and Quality Report
Certificate type
EPD
Certificate type

Thermally broken PVC-framed glass circular rooflight on GRP upstand.

Jump to:

01284 749051 Website

Application

Suitable for residential, administrative and office buildings, schools or industrial buildings.

Description

The Glass Skylight F100 is an energy-efficient skylight for rooms with high optical demands. Various shading options can be used to control the amount of light and heat entering the room through the rooflight.

The rooflight is completely pre-assembled on the upstand when delivered to site, and both the ventilated and the fixed variants of the rooflight can be installed on a flat roof immediately.

Glass Skylight F100 Circular Features and benefits:

Savings on heating costs and minimized risk of condensation.
Optional drive units integrated invisibly in the upstand.
Tested watertightness in heavy rain and during storms (impervious to driving rain, in accordance with BS EN 12208, Category E1500, Class 4).
Approved fall-through protection according to GS-Bau 18.
White, silk-matt appearance inside – no additional drywall construction required.
Optional connection to comfort control unit with remote controls.

General information

Color	White
Finish	Glazed
Material	Glass PVC Guidance for specification option: Polyvinyl chloride (PVC). Glass Reinforced Plastic (GRP)
Shape	Circle
Length	1000 mm 1500 mm
Width	1000 mm 1500 mm

Uniclass	Pr_30_59_72_31 Framed rooflightsPrimary
CAWS	L10/45 Rooflights L10/460 Rooflights

Product range	Glass rooflights

Specification data - Framed rooflights

Form	Flat.
Size	1000 mm Ø. Guidance for specification option: F100GC-S20. 1500 mm Ø. Guidance for specification option: F100GC-S21. Manufacturer guidance Structural roof opening size. Non-standard sizes are available on request.
Product performance	-
Whole window U-value	1.1 W/m2K.
Frame	-
Material	PVC.
Finish	-
Colour	White (RAL 9016).
Glazing or infill	-
Type	Insulating glass units. Guidance for specification option: Double glazed thermal insulating glass to meet CWCT, TN 92 Class 2 fragility. Non-standard glazing options are available on request.
Construction	Double skin. Guidance for specification option: 6 mm toughened safety glass/ 20 mm cavity/ 9.5 mm laminated safety glass. Toughened outer, laminated safety glass inner, low emissivity coatings, gas-filled cavities and warm edge spacers. Ug=1.1 W/m²k.
Colour	Clear.
Coating	UV protected. Manufacturer guidance Non-standard glazing options are available on request. Consult manufacturer and insert requirements.
Integral kerb	300 mm high fully insulated GRP upstand - factory fitted. Guidance for specification option: Non-standard upstand options are available on request.
Operation	-
Type	Fixed (non opening). Manufacturer guidance Non-standard motor options are available on request.

Resistance to wind load	To EN 12210, Class C4. Guidance for specification option: Stability against wind and snow loads.
Watertightness	To BS EN 12208, Category E1500, Class 4. Guidance for specification option: Watertight to 1500 pascals, representing high winds and driving rain.
Air permeability	Class AE 1050. Assembly airtight (including vents) to Class 4, EN 12207.
Sound insulation	Rwp 38 dB.
Light transmission	80%.
SolarTransmittance	G-Value 0.57.

Sustainability data

Contains Red List materials	No
Country of product manufacture	Germany
Material	Glass PVC Guidance for specification option: Polyvinyl chloride (PVC). Glass Reinforced Plastic (GRP)
