This product is no longer available

Application

For indoor use.

See manufacturer's literature for details on stains, dirt and similar surface defects.

Description

Postformed worktop profile with 28 mm or 38 mm chipboard, and high pressure laminate (HPL) facing.

Features and benefits:

  • The front edge is postformed, with a radius of 4 mm.
  • Food safe (according to EN 1186 and EN 13130).
  • Resistant to common household chemicals.
  • Steam, heat and abrasion resistant (according to DIN EN 438).
  • Impact resistant (according to ISO 13894).
  • Light-fast (according to DIN EN 438).
  • Antibacterial (according to JIS Z 2801).
  • PEFC™ certification available on request.
  • Can be cut to size - consult manufacturer for information.

Components (from top to bottom):

  • Overlay of 0.7 mm GetaLit HPL (to face side and front edge).
  • Decor paper.
  • Kraft papers.
  • Chipboard substrate (to DIN EN 312).
  • Water-resistant balancer (to reverse side and rear edge).
  • Moisture-resistant seal (at the joint along the front edge).

Applications:

For indoor use.

See manufacturer's literature for details on stains, dirt and similar surface defects.

General information
Specification data
Product Reference

GetaLit® AF133 Postformed Profile Worktop

Length

Basic range available, or can be cut to size. Consult manufacturer and insert requirements.

Width

Basic range available, or can be cut to size. Consult manufacturer and insert requirements.

Chipboard substrate -
Thickness

28 mm

38 mm

Type

P2

P2 hydro

Moisture-resistant.

Colour/ Finish

Consult manufacturer's literature and insert requirements.

Standard product features

Fire behaviour (to DIN EN 13501-1):

D-s2, d0.

Technical characteristics:

  • Formaldehyde emission (to EN 13986): Class E1.
  • Water vapour resistance (to DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Stain resistance (to DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Impact resistance (to ISO 13894-1): ≥15 N.
  • Heat resistance (to DIN EN 438-2): ≥ a moderate change in gloss level and/ or colour.
  • Light fastness (to DIN EN 438-2): Grey scale 4–5.
  • Abrasion resistance (to DIN EN 438-2): Moderate change in gloss level and/ or colour (decor related deviations are possible).
  • Antibacterial (to JIS Z 2801): 99.9% of bacteria is destroyed after 24 hours.
  • Distortion: ≤4 mm/m.
  • Edge fissures: Standard size: ≤10 mm; cut-to-size: ≤1.5 mm.

Product Options

Length:

  • Basic range: Allow +10/ -5 mm.
  • Cut-to-size: ±2.5 mm.

Width:

  • Basic range: ±0.55 mm (based on a width of 600 mm).
  • Cut-to-size: ±0.5 mm.

Chipboard substrate:

– Thickness:

  • 28 mm: Overall worktop thickness will be 29 mm (±0.5 mm).
  • 38 mm: Overall worktop thickness will be 39 mm (±0.5 mm).
