Geocolor Classic Concrete Pavers - Concrete Paving Blocks
Verified by manufacturer 2 months ago
Edelgijs
Edelgijs
Geocolor is a precast concrete block with different natural granulates to suit the finish required.
Application
Suitable for for use in domestic and light commercial applications.
Description
Geocolor Classic are face mix units with a washed concrete surface. After manufacturing the block is processed through a washing station where the top layer is treated, the visible surface of the GeoColor paving stones, which consists of colourfast, natural granulates of various sizes, are exposed. The paving has a 10 mm washed surface layer with an 80% colourfast course graded surface material finish and treated with an Ecowash surface impregnator.
Features and benfits:
- Manufactured to BS EN 1338.
- Functional, aesthetical and with a long lifespan.
- Various colour options available.
- Class A1 Non Combustible.
- CE marked.
General information
Color | Brown Black Grey Red Yellow |
Finish | Coated |
Material | Precast concrete |
Shape | Rectangle |
Length | 105 mm 210 mm |
Width | 70 mm 105 mm |
Height | 80 mm |
Uniclass | |
CAWS | Q24/110 Conventional concrete block paving Q24/10 Conventional concrete block paving |
Specification data - Concrete paving blocks
Standard | To BS EN 1338. |
Physical properties | |
Colour | Edelgrijs. |
Finish | Colourfast natural aggregate and Ecowash. |
Profile | |
Paver type | Regular plan form. |
Arrises | Bevelled. |
Dimensions and associated tolerances | |
Nominal sizes | 105 x 105 x 80 mm.210 x 105 x 80 mm.210 x 70 x 80 mm. |
Tolerances on diagonals | Length / width ± 2 mm, thickness ± 3 mm. |
Arrises | Bevelled. |
Weathering resistance | ≤ 1.0 kg/m².Guidance for specification option: On average. Manufacturer guidanceFreeze/thaw resistance. |
Abrasion resistance | ≥ 23.Manufacturer guidanceWide wheel abrasion test. |
Slip resistance | To BS EN 16165, PTV ≥ 0.3 (dry), ≥ 0.4.0 (wet).Guidance for specification option: With the GMG200. |
Density | 2300 kg/m³. |
BendingStrength | ≥ 4.0 MPa. |
TensileStrength | ≥ 3.6 MPa. |
Fire performance | Class A1 Non Combustible. |
Declaration of conformity | CE Marked to BS EN 1338:2003. |
