Geberit Varino floor drain, horizontal, d50 - Floor Drain
Verified by manufacturer 23 days ago
Geberit Varino floor drain, horizontal, d50.
Application
- For connecting sanitary appliances.
- For use inside buildings.
- For use as floor drain with vertical outlet.
Description
Geberit Varino floor drain, horizontal, d50: d=50 mm, d1=50 mm.
Features and benefits:
- Quality-monitored in accordance with EN 1253-3.
- Inlet rotatable by 280°.
- Inlet closed.
- Inlet for connecting one sanitary appliance.
- Height-adjustable with extension piece.
- Trap insert can be removed without tools.
- Shockproof.
- Resistant to chemicals.
- Inlet capacity 0.6 L/s.
- Depth of water seal 50 mm.
Included in the kit:
- Inlet connection piece made of PE-HD, ø 50 mm.
- Outlet made of PE-HD, ø 110 mm.
- Stainless steel grating.
- Trap insert.
- Protection box.
General information
Color | Grey |
Material | Polyethylene Stainless steel |
Shape | Square |
Length | 287 mm |
Width | 130 mm |
Height | 146 mm 193 mm |
Uniclass | |
CAWS | R11/5 Floor drains R11/315 Floor drains |
SKU Code | 388.023.00.1 |
Specification data - Floor gullies
Classification data | |
Properties | |
Body | |
Material | PE. |
Cover or grating | |
Cover or grating type | Slotted grating. |
Material | Stainless steel. |
Finish | Matt. |
Outlet | Horizontal two-part adjustable. |
Load class (minimum) | Class K 3 (3 kN). |
DischargeFlowRate | Discharge rate at 20 mm head of water: 1 L/s. Discharge rate at 10 mm head of water: 0.7 L/s. |
Sustainability data
Material | Polyethylene Stainless steel |
