Gatic Composite Access Covers

Composite single duct and multi span access covers and frames for use in pedestrian areas where an anti-slip, lightweight, lockable and aesthetic solution is required in environments up to B125 loading. All variants are suitable for 3 t slow moving pneumatic wheel loads, with a cover test load of 125 kN.

Features and Benefits:

• Available in solid or vented variants
• Lightweight and extremely strong, reducing the lifting risks to installers and inspectors
• Anti-slip properties in wet and dry conditions
• Secure and vandal resistant. The covers are lockable and cannot be removed without the correct lifting key, making unauthorized access virtually impossible
• Two standard lifting keys are supplied as standard, a short key for ease of inspection and a longer key which reduces the risk of operator injury
• Covers have a spring loaded lock which allows covers to be pushed into the frame - the lock will automatically engage, reducing the risk of covers left unlocked
• The composite covers will withstand test load and maximum permanent set criteria specified in BS EN 124, up to B125
• The clear opening width between the supporting frames is bigger than the pit/ chamber design to allow for minor deviations in pit construction dimensions
• Removable support beams for ease of access into the chamber area
