G-Blind Decomatic Vertical Blind System
Verified by manufacturer 6 months ago
Vertical Blind System.
Application
Suitable for commercial and domestic applications, Decomatic Vertical Blind systems can be wall or ceiling mounted, or recessed mounted for use on suspended ceilings.
Description
Goelst Decomatic Vertical Blind System standard units incorporate left, right, centre or split louvre stacking. Maximum width is 7 metres; maximum height is 5 metres.
Configuration/ features:
- Horizontally curved units: Stacking as standard; maximum track length 5.6 metres, maximum height 5.0 metres (greater heights available on application). Minimum radius 900 mm (127 mm louvre), 650 mm (89 mm louvre), 550 mm (63.5 mm louvre).
- Slope units: Louvre stacking at the high end; maximum track length 7.0 metres, maximum height 5.0 metres (greater heights available on application). Maximum angle 55° (greater angles available on application).
- Top and bottom track units: Optional left, right, centre or split louvre stacking; maximum width 4.5 metres, maximum height 5 metres mounted vertically or 2 metres mounted horizontally or sloping.
- Vertically curved units: Louvre stacking at the high end; maximum track length 5.6 metres, maximum height 5 metres (greater heights available on application). Minimum radius 500 mm.
The guide track is manufactured from aluminium AIl MgSi 0.5 F22, anodized according to DIN 17611, or powder coated in white or brown. The end caps, operating elements and brackets are selected to match the track colour; special colours in RAL shades for the profiles are available on request.
General information
Color | Silver Black White |
Finish | Powder-coated |
Material | Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | N10/240 Blinds |
Specification data - Vertical blinds
Classification data | |
Dimensions (minimum width x depth) | Manufacturer guidance
|
Headrail | |
Material | Aluminium. |
Colour | Silver. White. Black. |
Operation | Manual. 12 V - electric. Guidance for specification option: Electrical operation is available on all models, incorporating a 12 V tubular motor with safety clutch and electronic automatic overload cut out. Electronic end programming of the hanging, with a control switch or ten-channel remote control. |
Rail Configuration | Horizontally curved. Sloping. Top and bottom track. Vertically curved. |
Louvre size | 51 mm. Guidance for specification option: Special. 63.5 mm. Guidance for specification option: Standard. 80 mm. Guidance for specification option: Special. 89 mm. Guidance for specification option: Standard. 100 mm. Guidance for specification option: Special. 110 mm. Guidance for specification option: Special. 127 mm. Guidance for specification option: Standard. |
Other requirements | Guidance for specification option: The system includes side control, central control, side control cassette, slope window roller blinds with spring and variable stoppers, and a side guiding system; consult manufacturer for details. |
Type | G-Blind Decomatic Vertical Blind Type 9800/W. Guidance for specification option: Manual operation with chain and cord. Dimensions 40 mm wide x 25 mm height x 6 m long. G-Blind Decomatic Vertical Blind Type 9900/W Mono Gear. Guidance for specification option: Manual operation, mono gear. G-Blind Decomatic Vertical Blind Type 9900/W Traversing Wand. Guidance for specification option: Manual operation, traversing wand. G-Blind Decomatic Vertical Blind Type 9900/W/E Motorized. Guidance for specification option: Motorised, motorised tilting and sideways travel. |
Sustainability data
Material | Aluminium |
