Fusion Hand Dryer

Application

Suitable for washroom environments with minimal wall space, attaching directly to the basin or countertop in applications such as hotels, airports and hospitality environments.

Description

Hand dryer with a basin-mounted individual shell. It has automatic operation, a motor and a solid brass case. With an 500 W total power rating, the Fusion blasts air through a single nozzle and can dry hands in 15 seconds.


Features and benefits:

  • Contemporary, ergonomic design.
  • Solid brass casing gives ongoing protection against corrosion and vandalism.
  • The automatic 'no touch' operation ensures hygiene.
  • Over-basin drying helps reduce clean up, spills and wet floors.
  • Maximum output with minimal power consumption (500 W).
  • Built-in removable HEPA filter for hygienic operation with filtered air.
  • Automatic cut-off.
  • Reduced noise levels.
  • LED indicator clearly indicates dryer is in use.
  • Easy to install and maintain.
  • Available in a chrome finish.

General information

Color

Chrome

Finish

Chrome

Material

Brass

Shape

Tubular

Size

50 x 170 x 223 mm

WarrantyDescription

Two years

Uniclass 2015

Pr_40_70_62_37 Hand dryersPrimary

CAWS

N13/472 Hand dryers

Specification data - Hand dryers Enhanced data

Standards

CE.

RoHs.

Form

Hands-under.

Operation

Automatic.

Timer

Fixed.

Electrical supply

-

Power rating

500 W.

Frequency

50/ 60 Hz.

Body

-

Finish

Arctic white.

Brushed metal.

Polished chrome.

Product Reference

Fusion Hand Dryer

Rated operational voltage

220–240 V AC.

Ingress protection minimum

IP24.

Noise level at 1 m maximum

75 dB.

Installation

Basin mounted.

Drying time

15 seconds.

Air speed

90 m/s.

Thermal protection

Cut off above 70°C.

Net weight

4.4 kg.

Filter

HEPA filter.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
