Function + Flow Vinyl Tile Collection: Flow 5.0 Tile 4419V
Verified by manufacturer 5 days ago
Smooth 85114
Smooth 85114
Heavy commercial luxury vinyl tile (LVT).
Application
Suitable for commercial interiors.
Recommended installation methods (product specific):
- Quarter turn;
- Random;
- Monolithic;
- Brick;
- Ashlar.
Description
Heavy commercial luxury vinyl tile (LVT), available in four colours.
Features and benefits:
- CE marked.
- UKCA marked.
- Declaration of Performance (DoP): UK.DOP/0321/CPR/1222/1222/LVT.
- Use classification 33 Commercial Heavy to BS EN ISO 10874.
- FloorScore® certified and EPD available.
- 15-year commercial limited warranty.
- Electrostatic propensity rating of ≤2.0 kV (to EN 1815).
- Adhesive-free installation: IOBAC MagTabs™.
- Contributes towards LEED and WELL credits.
Please note: Colour and visual variation is inherent on all modular products. Consult manufacturer's datasheet for further details.
General information
Color | Beige Grey |
Finish | Other Guidance for specification option: ExoGuard+®. |
Material | Vinyl PVC |
Shape | Square |
Length | 914.4 mm |
Width | 914.4 mm |
Height | 5 mm |
Warranty description | 15 year |
Uniclass | |
CAWS | M50/110 Resilient floor tiling M50/10 Resilient floor tiling |
SKU Code | 4419V |
Specification data - Polyvinyl chloride (PVC) tiles
Classification data | |
Product reference | Function + Flow Vinyl Tile Collection: Flow 5.0 Tile 4419V. |
Standard | To BS EN ISO 10874. |
Use class | To BS EN ISO 10874, Class 33. |
Slip potential | |
Slip resistance value (SRV) (minimum)/ pendulum test value (PTV) (minimum) | To BS 7976-2, 68/ 24 dry/ wet. Guidance for specification option: To DIN 51130, R10 (shod ramp). |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0%. |
Size | 914.4 x 914.4 mm. |
Thickness | 5 mm. |
Colour and pattern | Smooth 85114. |
Surface finish | ExoGuard+®. |
Mass | 8.92 kg/m² (total mass). Guidance for specification option: Weight per box: 32.36 kg. |
FlammabilityRating | To EN 13501-1, Bfl-S1. |
Thermal resistance | To ISO 8302, 0.018 m² K/W. |
Castor chair rating | To EN 425, ISO 4918, No damage. |
Impact sound reduction | To BS EN ISO 10140, ΔLw 4 dB/ 21 dB with 2 mm underlay. |
Colour fastness | To BS EN ISO 105-BO2, 7/8. |
Light reflectance | 37.7. |
Dimensional stability | To EN ISO 23999, ≤0.15%. |
Third-party certification | FloorScore® and Environmental Product Declaration (EPD). |
Sustainability data
Country of material origin | China |
Material | Vinyl PVC |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 11.59 | |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
