Fuente C - E - R - Dog Fountains

Verified by manufacturer 2 days ago

FUENTE C - 0310050

Bailey Street Furniture Group Variant:

Rectangular steel fountain collection for outdoor use.

Jump to:
+44 (0)1625 322 888 Website

Application

Suitable to urban outdoor spaces.

Description

The Fuente drinking fountain collection is made of steel and available in various shapes, with each unit fixed to the base of the tank that includes an outlet and overfill pipe, a supply tube connection at the back, and a push-button tap with a spring return mechanism that stays closed when not in use.

The Fuente Dog fountain features an additional lower tap with a stainless steel bowl.

Features and benefits:

  • Push-button faucet with spring return mechanism.
  • Includes a drainage pipe with an overflow system in a rectangular basin and a slot for connecting a water supply pipe.
  • Available in three shapes and finishes.
  • Optional dog fountain attachment.

General information

Color

Black

Brown

Silver

White

Finish

Chrome

Powder-coated

Material

Steel

Cor-Ten

Stainless steel

Shape

Circle

Elliptical

Rectangle

Length

890 mm

Width

295 mm

Height

990 mm

Warranty description

Three year

Uniclass

Ss_40_15_75_25 Drinking fountain systemsPrimary

CAWS

N13/379 Drinking fountains

SKU Code

0310050

Specification data - Drinking fountain systems

Classification data

Components

Rectangular steel basin with removable grating.

Manufacturer guidance

Includes drainage pipe with an overflow system to prevent spills.

Material and finish

Brushed stainless steel.

Grate

Brushed stainless steel.

Tank type

Polyester powder-coated steel with wrinkle finish.

Taps

Chrome-plated brass.

Colour

-

Manufacturer guidance

Available in a range of colours from the standard Metalco colour range.

Consult manufacturer for details and insert requirements.

Form

Circular.

Dimensions

890 x 296 x 990 mm.

Manufacturer guidance

Length x width x height.

Weight

22 kg.

Operation

Push button faucet with a return spring.

Guidance for specification option:

Chrome-plated brass.

Fixing

Below ground installation.

Sustainability data

Contains Red List materials

No

Country of material origin

Italy

Country of product manufacture

Italy

Manufacturing plant location

Material

Steel
Cor-Ten
Stainless steel

Recyclability

Yes

Expected Life

Five year
