Description

The automatic sliding door FST is designed to offer solutions for the operation of balcony or terrace doors where a high sealant is required. Standard automatic doors do not provide a watertight or as high resistance as that provided by FST doors. This can be achieved with the use of window profiles from any curtain-wall system. Together with the clever FST design, a sealed, comfortable and secure system is provided. The innovation behind the façade/ terrace sliding door is the pop-out drive system that slides out of the façade and positions the leaf parallel to the fixed side screen. During closing the door again slides automatically back into the façade opening and closes flush. The FST system is available in a manual or automatic (dead-man controlled) version.

Benefits:

  • Sealed and secured terrace/ balcony door where no conventional automatic door could provide a solution.
  • Aesthetically designed with a fully flush outer skin that offers an unique and impressive look, provides a secure and totally unique solution.
  • Comfortable use even for large door leaves at your balcony or façade opening.
  • Air and water tightness solutions in different designs available.
  • Window functions, system can be stopped anywhere for ventilation purposes.
  • APS design for high sealant and security requirements by using a standard window profile.

General information
Size

Insert requirements.

Uniclass 2015 Sliding door and partition sets (Pr_30_59_24_80)
Specification data
Product Reference

FST

Size

Insert requirements.

Casing finish

Anodized

Brass

Bronze

Powder coated, RAL

Insert requirements.

Stainless steel, 1.4301 (304)

Stainless steel, 1.4401 (316)

Stainless steel, brushed 240 grain

Glass

Custom

Insert requirements.

Low iron (white)

Tinted

Control

Manual

Wireless, remote

Standard product features

Door leaf weight:

< 330 kg (< 400 kg on request).

Product Options

Size:

  • Opening: 550–3500 mm.
  • Height: 1200–3000 mm.

Technical data:

  • Rated voltage: 100–240 V AC/ 47–63 Hz.
  • Control voltage: 24 DVC.
  • Power consumption: 150 W.
  • Protection class: IP 20 (for protected internal use).
  • Control system: TA12 - V1.12.
  • Speed (fixed, approximate): 0.1 m/s.

Environmental:

  • Temperature range: -15°C to + 50°C.
  • Humidity range: Up to 85% relative humidity.
