FR7 - Underlay
Verified by manufacturer 4 months ago
EPD
Certificate type
Polyurethane rebond underlay.
Application
Suitable for flame retardant applications.
Suitable for the stretch-fit and double-stick installation of carpets
Description
Polyurethane rebond underlay suitable for flame retardant applications.
Features and benefits:
- Polyurethane rebond.
- End use classification (to BS 5808): HC/U, heavy contract use.
- Meets low VOC emission criteria.
- Resistance to cracking (not greater than 50 mm).
General information
Color | Yellow |
Material | Polyurethane |
Shape | Rectangle |
Length | 11000 mm |
Width | 1370 mm |
Height | 7 mm |
Uniclass |
Specification data - Cellular plastics underlays
Standard | To BS 5808 and BS EN 14499. |
Use class | HC/U. |
Thickness (minimum) | 7 mm. |
Recycled content | 95%. |
Density | 145 kg/m³. |
Breaking strength | >90 N (length), >50 N (width). |
Odour | No objectionable odour. |
Colour | Yellow with reinforcing mesh. |
Thermal resistance | 1.99 togs. |
Impact sound reduction | 34 dB. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | At the end of the underlays useful life it can be 100% recycled. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
EPD
Third party certifications
EPD
GENERAL-PURPOSE POLYURETHANE UNDERLAY
Literature
PU Underlay
Case studies
Marina Bay Sands, Singapore (60,000m2 Durafit 500, 34,000m2, New Supreme, 57,000m2 Softwalk and 32,000m2 FR7).
