Floor Architecture III Collection: Fragment Ecoworx S® Carpet Tile 5T579

Verified by manufacturer 5 days ago

Marble 53100

Shaw Contract Variant:

Multi-level pattern loop carpet tile.

Jump to:
+44 (0) 20 79614120 Website

Application

Suitable for commercial interiors.

Recommended installation methods (product specific):

  • Monolithic;
  • Quarter turn;
  • Brick;
  • Ashlar;
  • Random.

Description

Multi-level pattern loop carpet tile, available in nine colours.

Features and benefits:

  • 100% solution dyed polyamide pile fibre with 100% recycled content.
  • Use classification 33 Commercial Heavy to EN 1307.
  • Cradle to Cradle™ Silver Certified and EPD available.
  • Lifetime commercial limited warranty.
  • We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme.
  • Adhesive-free installation: IOBAC MagTabs™.
  • Contributes towards LEED, BREEAM and WELL credits.

General information

Color

Black

Grey

Material

Polyamide

Polyolefin

Polyethylene

Guidance for specification option:

Polyethylene terephthalate (PET).

Shape

Square

Length

500 mm

Width

500 mm

Height

5.6 mm

Warranty description

Lifetime

Uniclass

Pr_35_57_11_62 Pile carpet tilesPrimary

CAWS

M50/130 Carpet tiling

M50/15 Carpet tiling

SKU Code

5T579

Specification data - Pile carpet tiles

Classification data

Product reference

Floor Architecture III Collection: Fragment Ecoworx S® Carpet Tile 5T579.

Style

Tufted loop pile.

Guidance for specification option:

Multi-level pattern loop.

Tufted 1/12", 47.2 per 100 mm.

Number of tufts: 193 000/m².

Material

Eco Solution Q100® Polyamide 6.

Classification

-

Standard

To BS EN 1307.

Third-party certification

Cradle to Cradle™: Silver and Environmental Product Declaration (EPD).

Level of use class

To BS EN 1307, class 33.

Luxury rating class

LC1.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

53%.

Size

500 x 500 mm.

Colour and pattern

Marble 53100.

Dye method

100% solution dyed.

Primary backing

PET non-woven.

Secondary backing

Ecoworx S® polyolefin plastomer.

Total thickness

5.6 mm.

Guidance for specification option:

Pile thickness: 1.7 mm.

Mass

630 g/m² (nominal total pile mass).

Guidance for specification option:

2287 g/m² (total mass).

Pile density

To ISO 8543, 0.115 g/cm³.

Dimensional stability

To EN 986, ≤0.2%.

Sound insulation

To ISO 10140, 26 dB.

Sound absorption

To ISO 354/116540, 0.20 αw/ Class E.

Thermal resistance

To ISO 8302, 0.069 m²K/W.

Colour fastness

To ISO 105-B02, >6.

FlammabilityRating

To EN 13501-1, Bfl-S1 (adhered testing).

Castor chair rating

To EN 985, ≥2.4.

Slip resistance

To ISO 13893, Pass.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Polyamide
Polyolefin
Polyethylene

Guidance for specification option:

Polyethylene terephthalate (PET).

Carbon dioxide equivalent

Carbon dioxide equivalent, as defined in BS EN 15804

Self-declared

Stage
Normalised unit (kg CO₂ eq/kg)
Declared unit (kg CO₂ eq/m²)
Stage:A1–A3 ('Production stage')
Normalised unit :
Declared unit : 4.14

Lower emissions

Recyclability

Recyclable

Guidance for specification option:

re[TURN] TakeBack scheme.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

53 %
