Floor Architecture III Collection: Fragment Colours Ecoworx S® Carpet Tile 5T505
Verified by manufacturer 5 days ago
Oatmeal 04111
Oatmeal 04111
Multi-level pattern loop carpet tile.
Application
Suitable for commercial interiors.
Recommended installation methods (product specific):
- Monolithic;
- Quarter turn;
- Brick;
- Ashlar;
- Random.
Description
Multi-level pattern loop carpet tile, available in 18 colours.
Features and benefits:
- CE marked to EN 14041:2004/AC 2006.
- UKCA marked.
- Declaration of Performance (DoP): UK.DOP/0338/CPR/1222/0323/EST.
- 100% solution dyed polyamide pile fibre with 100% recycled content.
- Use classification 33 Commercial Heavy to EN 1307.
- Cradle to Cradle™ Silver Certified and EPD available.
- Lifetime commercial limited warranty.
- We want it back: At the end of its useful life, we’ll reclaim and recycle or reuse our carpet tiles through our reTURN scheme.
- Adhesive-free installation: IOBAC MagTabs™.
- Contributes towards LEED, BREEAM and WELL credits.
General information
Color | Black Grey Gold Green Blue |
Material | Polyamide Polyolefin Polyethylene Guidance for specification option: Polyethylene terephthalate (PET). |
Shape | Square |
Length | 500 mm |
Width | 500 mm |
Height | 5.5 mm |
Warranty description | Lifetime |
Uniclass | |
CAWS | M50/130 Carpet tiling M50/15 Carpet tiling |
SKU Code | 5T505 |
Specification data - Pile carpet tiles
Classification data | |
Product reference | Floor Architecture III Collection: Fragment Colours Ecoworx S® Carpet Tile 5T505. |
Style | Tufted loop pile. Guidance for specification option: Multi-level pattern loop. Tufted 1/12", 47.2 per 100 mm. Number of tufts: 188 000/m². |
Material | Eco Solution Q100® Polyamide 6. |
Classification | |
Standard | To BS EN 1307. |
Third-party certification | Cradle to Cradle™: Silver and Environmental Product Declaration (EPD). |
Level of use class | To BS EN 1307, class 33. |
Luxury rating class | LC1. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 53%. |
Size | 500 x 500 mm. |
Colour and pattern | Oatmeal 04111. |
Dye method | 100% solution dyed. |
Primary backing | PET non-woven. |
Secondary backing | Ecoworx S® polyolefin plastomer. |
Total thickness | 5.5 mm. Guidance for specification option: Pile thickness: 1.7 mm. |
Mass | 634 g/m² (nominal total pile mass). Guidance for specification option: 2632 g/m² (total mass). |
Pile density | To ISO 8543, 0.118 g/cm³. |
Dimensional stability | To EN 986, ≤0.2%. |
Sound insulation | To ISO 10140, 26 dB. |
Sound absorption | To ISO 354/116540, 0.20 αw/ Class E. |
Thermal resistance | To ISO 8302, 0.065 m²K/W. |
Colour fastness | To ISO 105-B02, >6. |
FlammabilityRating | To EN 13501-1, Bfl-S1 (adhered testing). |
Castor chair rating | To EN 985, ≥2.4. |
Light reflectance | 27. |
Slip resistance | To ISO 13893, Pass. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Polyamide Polyolefin Polyethylene Guidance for specification option: Polyethylene terephthalate (PET). |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 4.14 Lower emissions | |
Recyclability | Recyclable Guidance for specification option: re[TURN] TakeBack scheme. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 53 % |
