FirePro Ei60 Single Glazed Partition System and Doorset

FirePro Ei60 Single Glazed Partition System and Doorset

Planet Third party certifications:
  • Certifire Certificate

    Certifire Certificate

    Certificate type

Single glazed partition system and doorset with an Ei60 (60/60) fire rating.

Jump to:
+44 (0)1444 247933 www.planetpartitioning.co.uk

Application

All sectors: Commercial, Education, Healthcare, MOD, Airport & Rail, Industrial, Hospitality, Residential, & Public.

Consult manufacturer for details.

Description

Single glazed partition system and doorset with an Ei60 (60/60) fire rating. FirePro partitions and doorsets are available in a range of glazing and performance options (specified separately).


Please note that acoustic, fire rated and structural certification and support for Planet products and systems is available on a project-specific basis. Please contact the specification team directly for further information.

General information

Finish

PPC

Polyester powder-coated.


Satin

240 grit satin polished stainless steel.

Color

Other

Polyester powder-coated, RAL.


Silver

Stainless steel.

Material

Steel

Stainless steel

Glass

Shape

To suit project requirements; consult manufacturer for further details.

-

Size

To suit project requirements; consult manufacturer for further details.

-

WarrantyDescription

Dealt with on a project specific basis as part of the O&M process; consult manufacturer for details.


-

Uniclass 2015

Pr_25_71_57_60 Partition panelsPrimary
Ss_25_12_65_65 Panel partition systems

CAWS

K30/130 Relocatable partition system

K30/10 Relocatable partition system

Specification data - Partition panels Enhanced data

Third party accreditation

ISO 9001-UKAS (Quality); ISO 14001-UKAS (Environmental); Constructionline-Gold; Acclaim (SIPP); Achilles (Building confidence, SIPP); EPD - material accreditation & compliance; FIS Member; Considerate Construction; FORS Bronze; Build Profile.

EPD - material accreditation & compliance: Consult manufacturer for details (glass, PPC, aluminium, timber, ironmongery, waste, adhesive and more).

Unit size

-

Thickness

89 mm.

104 mm deep x 89 mm wide box and bead.

Partition height (nominal)

Consult with manufacturer to ensure compliance with certification and insert requirements.


-

Width (nominal)

Consult with manufacturer to ensure compliance with certification and insert requirements.


-

Deflection allowance (maximum)

-

Head

±25 mm deflection head 116 mm deep x 142 mm wide box and bead.

Certain configurations not available with deflection option - consult with manufacturer.

Floor

Consult with manufacturer for system weight.

-

Verticals

48 mm deep x 89 mm wide box and bead.

Panel partition type

Framed glass - single centre glazed.

Framing, junctions, corners

Corners: Framed 139 mm deep x 139 mm wide box and bead.

Joint treatment

-

Type

Mullion: 72 mm deep x 89 mm wide; transom: 86 mm deep x 89 mm wide.

Finish and colour

Polyester powder-coated, RAL.

Insert colour requirement/ gloss level.


240 grit satin polished stainless steel.

Glazed panels

-

Type

Consult with manufacturer to ensure compliance with test/ assessment data.

Single centre glazed: 27 mm fire glass.

Door arrangement

-

Type

Single leaf door, single action.

Single leaf door, double action.

Unequal leaf doors, single action.

Unequal leaf doors, double action.

Double leaf doors, single action.

Double leaf doors, double action.

Door frames

60 mm deep x 89 mm wide head; 82 mm deep x 89 mm wide stiles.

Door leafs

-

Type

Fully glazed 27 mm fire glass.

Frame to glazed leaf:

  • 76 mm deep x 74 mm wide head.
  • 100 mm deep x 73 mm wide base.
  • 71 mm deep x 74 mm wide stiles.


Ceiling

-

Type

Fire rated construction - consult with manufacturer for interface detail and insert requirements.


-

Method of support

Consult manufacturer for support detail and insert requirements.


-

Perimeters, skirtings, sills

102 mm deep x 82 mm wide box and bead.

Hardware

Consult manufacturer and insert requirements:


  • Dorma BTS75/80 non hold-open floorspring- EMB variants (electronic hold open linked to fire alarm).
  • Geze TS550 NV non hold-open floorspring - EMB variants (electronic hold open linked to fire alarm)
  • Free swing pivot bearing used with exposed Dorma TS93 B overhead closer.
  • SSS Back to back shorter pull handles bolted through either the glass leaf or full height handle through the top and bottom rails.
  • Manual locking: top and/ or bottom manual lock with cylinder and thumbturn.


Access control:

  • Gem EB195 electronic dropbolt concealed in the doorframe head
  • Abloy 351 'V' lock concealed in doorframe head.
  • Surface mounted mag-lock (single action doors only, secure or non secure side).



-

Seals

Kerafix ceramic fibre tape.

Cable management and outlets

Not required.

Tech panel, 82–400 mm deep x 91 mm.

Other features

Fanlights, sidelight and screens are available; consult with manufacturer and insert requirements


-

Product Reference

FirePro Ei60 Single Glazed Partition System and Doorset

Manifestation

To architects choice and in accordance with the requirements of Approved Document K.


Allowance of 2 nr rows 50 mm dots or square (minimum) Opal Frost.

Insert requirements.


Artwork and custom manifestation to client design.

Insert requirements.


StrengthGrade

Consult with the manufacturer to ensure the system complies with current regulations BS 5234:1992 non load-bearing screens not protecting a change in adjacent floor level of >380 mm.


For glass load resistance criteria;

  • BS 5234 not applied to “all glass partition screens”.
  • Nominal line load criteria of “short-term impact load” utilised.
  • 0.36 kN/m applied as linear load at 1100 mm above FFL.
  • Glass deflection limited to L/65 or 25 mm, whichever is less under load.
  • Maximum deflection and stress in accordance with the glass performance requirements of EN 572/ EN 12150/ EN 12543/ EN 14179 (where heat soaked).


Building regulations Part N (BS 6262 & BS EN 12600) + InsStucEng publication “structural use of glass in buildings” insert as required:

  • 0.36 kN/m (default load).
  • 0.74 kN/m.
  • 1.5 kN/m.


BS 6180:2011 barriers in and about buildings for Atria or protected change in adjacent floor level of >380 mm.

Horizontal uniformly distributed line load 1100 mm above FFL (glass deflection limited to L/65 or 25 mm, whichever is less relative to glass fixings).

Structural glass based on line-load and attendant UDL + point load, insert as required:

  • 0.74 kN/m.
  • 1.5 kN/m.
  • 3.0 kN/m.


-

Acoustic performance

Doorset: 38 dB Rw (through glass only); Glazing: 43 dB Rw (through glass only).

Fire insulation

Ei60 (60/60 Integrity and Insulation)

Partition

Framed glass - Single centre glazed.

Fasteners

To manufacturer's specification, type, length and frequency to suit substrates.

Joint treatment

Mullion: 72 mm deep x 89 mm wide; transom: 86 mm deep x 89 mm wide.

Colour/ Finish:

Polyester powder-coated RAL or 240 grit satin polished stainless steel.

See 'Joint treatment: Finish and colour' above for details.

System accessories

None.

Steel upstand support framework up to 450 mm deep.

Providing fire certification from slab to soffit with continuous threshold.

Samples required

Consult with manufacturer.


-

Environmental information

Contains Red List materials

No

No substance on the “Candidate List of Substances of Very High Concern for authorisation” derived under REACH is present either above the limits for registration with the European Chemicals Agency or in excess of 1 weight–% of the product.


Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recyclability

100%

Steel and glass.

Recycled content

17–28% for glass.

15–20% for steel.

-
