Fig. M525 Pressure Reducing Valve
Verified by manufacturer 10 days ago
DN65: Fig. M525
DN65: Fig. M525
Bronze pressure reducing valves, PN25.
Application
Suitable for drinking water applications only (medium use), up to 85°C.
Description
Bronze pressure reducing valves, PN25.
Features and benefits:
- PRVs enable control of pressure from boosted cold water supplies to match site requirements.
- Simple to install.
- Features an integral strainer preventing debris from affecting valve performance.
- WRAS Approved.
- Adjustable outlet pressure from 1–8 bar.
- Conforms to BS EN 1567.
General information
Color | Yellow Guidance for specification option: Body. |
Material | Brass Guidance for specification option: Internal parts. Steel Rubber Guidance for specification option: EPDM seal. Stainless steel Guidance for specification option: Internal parts. Bronze Guidance for specification option: Body and internal parts. |
Uniclass | |
CAWS | S90/650 Flow reducing/ servicing valves S90/650 Flow-reducing/ servicing valves S14/393 Pressure regulators |
Product range |
Specification data - Pressure-regulating valves
Standard | General conformity to BS EN 1567. |
Third-party certification | Water Regulations Advisory Scheme-approved, DVGW and PED 97/23/EC.. |
Form | Water pressure reducing. |
Adjustment | Adjustable. |
Operating conditions | |
Temperature (maximum) | 85°C. |
Maximum working pressure | 25 bar. |
Connections | Flanged to BS EN 1092-3. |
Accessories | Not required.Pressure gauge.Guidance for specification option: Two pressure gauges to measure inlet and outlet pressure available with axial or vertical threaded connection and should be ordered separately. |
Inlets/outlets diameter | DN65. Manufacturer guidanceNominal. |
Dimensions | 185 x 290 x 235 x 93 x 145 mm. Manufacturer guidanceNominal A x B x C x D x E. |
Weight | 20 kg. |
Material (all components) | Body and internal parts: Bronze CC499K, Internal parts: Brass CW614N and stainless steel grade 316, Spring: Spring steel, Strainer screen: Stainless steel grade 304, Seal: EPDM. Manufacturer guidance
|
Integral accessories | Strainer. |
PressureRange | Temperature: -10 to +85°C: 25 bar. Manufacturer guidanceShell tested up to PN40. |
DownstreamPressure | 1–6 bar. Guidance for specification option: Outlet pressure range. Manufacturer guidancePreset outlet pressure: 3 bar. |
Sustainability data
Country of product manufacture | Europe |
Material | Brass Guidance for specification option: Internal parts. Steel Rubber Guidance for specification option: EPDM seal. Stainless steel Guidance for specification option: Internal parts. Bronze Guidance for specification option: Body and internal parts. |
Recyclability | Recycle locally |
Expected Life | 20 year |
