Fig. 100YL Ball Valve

Name: Fig. 100YL Ball Valve
Brand: Hattersley
SKU: 6gQXcUmff2D39Bk2GWjnQb

Verified by manufacturer 14 days ago

DN8

A threaded DZR, lever operated gas ball valve.

Jump to:

Description

A threaded DZR, lever operated gas ball valve.

Features and benefits:

Color	Yellow Guidance for specification option: Brass valve body, ball, bonnet, stem and packing nut. PVC handle sleeve. Silver Guidance for specification option: Dacromet plated hex-nut and handle.
Material	Brass Guidance for specification option: Body, packing nut, ball, bonnet and stem.

Uniclass	Pr_65_54_95_06 Ball valvesPrimary
CAWS	S90/625 Ball valves S91/350 Gas ball valves S90/625 Ball valves S91/350 Gas ball valves

Material	Body, ball, bonnet and stem: DZR Brass CW602N, Packing nut: Brass CW617N, Handle sleeve: PVC, Seats and packing gland: PTFE, O-ring: NBR. Guidance for specification option: PTFE: Polytetrafluoroethylene. NBR: BS EN549 approved nitrile butadiene rubber (NBR).
Connections	UK end connection to BS EN 10226-2:2005. Guidance for specification option: Formerly BS21 taper. US end connection to ANSI B1.20.1:1983.
Finish	Hex-nut and handle: Dacromet plated steel.

Standards	To BS EN 331:1998.
Inlets/outlets diameter	DN8.
Dimensions	46 x 12 x 89 x 41 mm. Manufacturer guidance All dimensions are nominal (L x L1 x L2 x H).
Weight	152 g.
Operator	Lever. Guidance for specification option: Quarter turn.
PressureRange	Temperature (Non-gas application): -10 to +100°C: 25 bar, 110°C: 23.5 bar, Temperature (Gas application): -20 to +60°C: 5 bar. Guidance for specification option: Non-gas application. Manufacturer guidance Intermediate pressure ratings shall be determined by interpolation.

Material	Brass Guidance for specification option: Body, packing nut, ball, bonnet and stem.
Recyclability	Recycle locally
Expected Life	20 year
