Ferrocast® Post, Rail and Tension Wire System
Description

A bespoke polyurethane post, rail and wire system, comprising posts, rails and stainless steel tension wires.

Features:

  • Ferrocast® is an engineering grade polymer which does not rust or corrode, and will not chip and requires virtually no maintenance. Supplied with a two part polyurethane coating as standard.
  • The posts are Ferrocast®, cast around a steel core.
  • Available in a full standard range of RAL colours.
  • Designed for waterfronts, on bridges and near steep inclines.
  • A bespoke design service is available to create exact replicas of any design.
  • Marshalls Street Furniture offer a full site survey and installation service.

Fixing:

  • Base plate: A positive bolting system should be selected by the installer based on the type and condition of the substrate, taking into account any applicable close edges and thicknesses.
  • Ground (root) fixed: The posts are designed to be situated directly into a C30, medium slump grade concrete mix.

General information
Finish

Gloss

Semi-gloss

Matt

Features

Ferrocast® is an engineering grade polymer which does not rust or corrode, and will not chip and requires virtually no maintenance. Supplied with a two part polyurethane coating as standard

The posts are Ferrocast®, cast around a steel core

Available in a full standard range of RAL colours

Designed for waterfronts, on bridges and near steep inclines

A bespoke design service is available to create exact replicas of any design

Marshalls Street Furniture offer a full site survey and installation service

Uniclass 2015
Ss_25_15_60_17 Composite post and rail barrier systemsPrimary
CAWS

Q41/110 Pedestrian restraint systems in metal

Specification data - Composite post and rail barrier systems
Product Reference

Ferrocast® Post, Rail and Tension Wire System

Layout

As drawing ___

Colour

RAL ___

Finish

Gloss

Semi-gloss

Matt

Accessories

Not required

Chain link facility

Crests as drawing ___

Logos as drawing ___

DDA handrail

Illuminated handrail

Swivel post and sockets

Product Options

Colour:

- Ferrocast Gloss colours:

  • RAL 1001, Beige/ RAL 1003, Signal Yellow/ RAL 1006, Maize Yellow/ RAL 1011, Brown Beige/ RAL 1013, Oyster White/ RAL 1015, Light Ivory/ RAL 1016, Sulphur Yellow/ RAL 1018, Zinc Yellow/ RAL 1021, Rape Yellow/ RAL 1028, Melon Yellow/ RAL 2000, Yellow Orange/ RAL 2002, Vermilion/ RAL 2004, Pure Orange/ RAL 2011, Deep Orange/ RAL 3000, Flame Red/ RAL 3003, Ruby Red/ RAL 3004, Purple Red/ RAL 3011, Brown Red/ RAL 3016, Coral Red/ RAL 3018, Strawberry Red/ RAL 3020, Traffic Red/ RAL 4003, Heather Violet/ RAL 4004, Claret Violet/ RAL 4008, Signal Violet/ RAL 5000, Violet Blue/ RAL 5002, Ultramarine Blue/ RAL 5003, Sapphire Blue/ RAL 5005, Signal Blue/ RAL 5010, Gentian Blue/ RAL 5011, Steel Blue/ RAL 5013, Cobalt Blue/ RAL 5015, Sky Blue/ RAL 5022, Night Blue/ RAL 6000, Patina Green/ RAL 6002, Leaf Green/ RAL 6005, Moss Green/ RAL 6011, Reseda Green/ RAL 6014, Reed Green/ RAL 6018, Yellow Green/ RAL 6021, Pale Green/ RAL 6028, Pine Green/ RAL 6029, Mint Green/ RAL 6034, Pastel Turquoise/ RAL 7000, Squirrel Grey/ RAL 7001, Silver Grey/ RAL 7005, Mouse Grey/ RAL 7011, Iron Grey/ RAL 7012, Basalt Grey/ RAL 7016, Anthracite Grey/ RAL 7023, Concrete Grey/ RAL 7031, Blue Grey/ RAL 7032, Pebble Grey/ RAL 7035, Light Grey/ RAL 7040, Window Grey/ RAL 7042, Traffic Grey A/ RAL 8001, Ochre Brown/ RAL 8007, Fawn Brown/ RAL 8011, Nut Brown/ RAL 8014, Sepia Brown/ RAL 8016, Mahogany Brown/ RAL 8019, Grey Brown/ RAL 8028, Terra Brown/ RAL 9005, Jet Black/ RAL 9006, White Aluminium/ RAL 9007, Grey Aluminium/ RAL 9010, Pure White/ RAL 9016, Traffic White.

- Ferrocast Semi-gloss colours:

  • RAL 1001, Beige/ RAL 1013, Oyster White/ RAL 1015, Light Ivory/ RAL 2002, Vermilion/ RAL 3003, Ruby Red/ RAL 3020, Traffic Red/ RAL 4008, Signal Violet/ RAL 5002, Ultramarine Blue/ RAL 5003, Sapphire Blue/ RAL 5010, Gentian Blue/ RAL 5013, Cobalt Blue/ RAL 5015, Sky Blue/ RAL 6005, Moss Green/ RAL 7001, Silver Grey/ RAL 7016, Anthracite Grey/ RAL 7031, Blue Grey/ RAL 7032, Pebble Grey/ RAL 7035, Light Grey/ RAL 7042, Traffic Grey A/ RAL 8014, Sepia Brown/ RAL 9010, Pure White/ RAL 9016, Traffic White.

- Ferrocast Matt colours:

  • RAL 1003, Signal Yellow/ RAL 1006, Maize Yellow/ RAL 1013, Oyster White/ RAL 1015, Light Ivory/ RAL 1018, Zinc Yellow/ RAL 1021, Rape Yellow/ RAL 1028, Melon Yellow/ RAL 2000, Yellow Orange/ RAL 2002, Vermilion/ RAL 2004, Pure Orange/ RAL 3000, Flame Red/ RAL 3003, Ruby Red/ RAL 3004, Purple Red/ RAL 3020, Traffic Red/ RAL 4008, Signal Violet/ RAL 5002, Ultramarine Blue/ RAL 5003, Sapphire Blue/ RAL 5004, Black Blue/ RAL 5010, Gentian Blue/ RAL 5011, Steel Blue/ RAL 5013, Cobalt Blue/ RAL 5015, Sky Blue/ RAL 5022, Night Blue/ RAL 6000, Patina Green/ RAL 6002, Leaf Green/ RAL 6005, Moss Green/ RAL 6018, Yellow Green/ RAL 7000, Squirrel Grey/ RAL 7001, Silver Grey/ RAL 7005, Mouse Grey/ RAL 7011, Iron Grey/ RAL 7012, Basalt Grey/ RAL 7016, Anthracite Grey/ RAL 7023, Concrete Grey/ RAL 7031, Blue Grey/ RAL 7032, Pebble Grey/ RAL 7035, Light Grey/ RAL 7042, Traffic Grey A/ RAL 8011, Nut Brown/ RAL 8014, Sepia Brown/ RAL 8019, Grey Brown/ RAL 8028, Terra Brown/ RAL 9010, Pure White/ RAL 9016, Traffic White.

Layout:

  • Systems can be created to suit individual requirements.
  • Corners and bends can be accommodated and banisters and handrails that are compliant with DDA requirements can be produced.

Accessories:

  • Crests and logos can be incorporated into the posts.
  • DDA handrail: An additional 50 mm diameter handrail can be provided to suit DDA requirements (these can also be added to existing barriers).
  • Facilities for chain links can be supplied to restrict access to entrances.
  • Illuminated handrails are available.
  • A swivel post and socket is available to allow adjustment up to 37° to match the gradient of any ramp, staircase or steep incline.
