ES101 TremBlock DPM GT - Universal Damp Proof Membrane
Verified by manufacturer 3 days ago
One coat, solvent free, low viscosity, two-component epoxy resin damp proof membrane (DPM).
Application
Suitable for use as a guaranteed surface damp proof membrane with a single coat, where a structural damp proof membranes may not be present.
Description
One coat, solvent free, low viscosity, two-component epoxy resin damp proof membrane (DPM).
Features and benefits:
- High bond strength.
- Cost effective single coat application, reducing time on site.
- Protects the final floor covering from residual construction, moisture and rising damp.
- Can be applied where a structural damp proof membrane is not present or is ineffective.
- Accommodates up to 98% relative humidity (RH) - theoretically 99.9% RH.
- Increased coverage up to 38%, 25–33 m² (dependent on application thickness).
- Can be applied to anhydrite/ calcium screed-based screeds (without underfloor heating where readings are up to 87% RH).
- Solvent free (in-line with BREEAM compliance).
- Eco-friendly.
- Suitable for concrete, sand and cement screeds incorporating underfloor heating (surface temperature must not exceed 27°C in accordance with BS 8203 and BS 5325).
All aspects of the installation must be in accordance with the requirements of British Standard BS 8203 Installation of Resilient Floor Coverings – Code of Practice or BS 5325 – British Standard Code of practice for installation of textile floor coverings, BS 8204 - Screeds, bases and in-situ floorings and supplementary specifications.
See manufacturer's datasheet for preparation and application requirements.
General information
Color | Black |
Material | Epoxy resin |
Shape | Formless |
Warranty description | Other Guidance for specification option: Tremco CPG UK Limited products are manufactured to rigid standards of quality. Any product which has been applied (a) in accordance with Tremco CPG UK Limited written instructions and (b) in any application recommended by Tremco CPG UK Limited, but which is proved to be defective, will be replaced free of charge. |
Uniclass | |
CAWS | J30/130 Cold-applied damp-proofing J30/10 Cold-applied damp-proofing |
SKU Code | ES101 |
Specification data - Liquid tanking resins
Classification data | |
Composition | Epoxy. Guidance for specification option: Flexibilized epoxy, which contains wetting aids and penetrants. |
Cure time | Light foot traffic: 14 hours. Overcoat time: 14–24 hours. Full chemical cure: 5–7 days. Manufacturer guidanceAt +20°C. |
Service temperature range | -20 to +80°C. |
Coverage | Approximately 25–33 m² per 10 kg unit. Guidance for specification option: Consult manufacturer for details. Depending on method of application and condition of substrate to give a dry film thickness of approximately 250–350 microns per coat. |
Sustainability data
Material | Epoxy resin |
