Elegance Swing Door

Application

Automatic swing door suitable for large complex entrances.

The largest automatic swing door installed is six metres high.

Description

Automatic swing door available in multiple dimensions and designs.


Features and benefits:

  • Available in a variety of single, double, multi and straight or curved configurations.
  • Can incorporate in-ground drive units for swing doors.
  • Motors for automatically opening door leaves weighing up to 3000 kg are available.
  • Door leaves are available in stainless steel, aluminium, copper, solid glass and sound-proof styles.
  • Made to measure in accordance with the client’s height and width specifications.


General information

Finish

Special finishes on request, consult manufacturer for options.

Stainless steel

Copper

Bronze

Aluminium

Polyester powder coated

Material

Glass

Steel

WarrantyDescription

Lifetime with service contract

Please contact Bauporte for further information.

Size

Doors are made to measure in accordance with height and width specifications.

Uniclass

Ss_25_30_20_25 Doorset systemsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Doorset systems Enhanced data

Doorset

-

Type

Composite doorsets.

Doors constructed from 12 mm clear safety glass, welded through stainless steel frames overclad with chosen finish.

Glazing

Vision panels.

Over panels

Not required.

Required.

Over panels are available.

Side panels

Not required.

Required.

Side panels are available.

Hardware

As required.

Product Reference

Elegance Swing Door - Single

Elegance Swing Door - Double

Finish

Door frame finish.

Stainless steel.

Solid glass.

Copper.

Bronze.

Aluminium.

Show more

Height

1930–6000 mm+.

Available in 1 mm increments.

Weight

<3000 kg.

Door weight.

Door locking

Manual.

Automatic.

Options

Glazing options.

Clear.

Low iron.

Coloured.

Fritted.

Special glazing options.

Consult manufacturer for options.

Safety

Designed, manufactured and installed to EN 16005.

Power supply

Not required.

230 V/50 Hz.

Automatic only.

Drive unit

Underfloor drive unit.

Over door drive unit.

Under structural flooring slab.

Door wings

One.

Elegance Swing Door - Single.

Two.

Elegance Swing Door - Double.

ClearWidth

1000 mm+.

Available in 1 mm increments. To comply with Access to and use of buildings: Approved Document M.
