Elegance Linear Sliding Door
Automatic sliding doors available in single, double, telescopic and multiple configurations.
Application
Linear sliding door for commerical building entrances.
Description
Automatic sliding doors available in single, double, telescopic and multiple configurations.
Features and benefits:
- Automatic drive mechanism systems developed for door leaves with weights of up to 3000 kg.
- Door leaves available in stainless steel, aluminium, copper, full glass and in fire resistant, smoke-proof and sound-proof variants.
- Optional security function with swipe cards.
- Available with the drive mechanism mounted in the ceiling above the door or the floor beneath the door.
General information
FinishSpecial finishes on request, consult manufacturer for options. | Stainless steel Copper Bronze Polyester powder coated |
Material | Glass Steel |
WarrantyDescription | Lifetime with service contract Please contact Bauporte for further information. |
Size | Available in a range of bespoke sizes. |
Uniclass | |
CAWS | L20/60 Doors L20/520 Sliding doors |
Specification data - Sliding doorset systems Enhanced data
Doorset | - |
Type | Sliding door and partition sets. |
Glazing | Vision panels. |
Breakout facility | Not required.Required.Available on request. |
System accessories | Not required.Matting.Water drainage reservoir.Integrated into the mat well or canopy. Security resistance options.RC2, RC3, RC4, SR2 and Ballistic options available - consult manufacturer for options. Heaters. |
Product Reference | Elegance Linear Sliding Door - Single Elegance Linear Sliding Door - Bi-parting Elegance Linear Sliding Door - Telescopic |
Finish | Stainless steel. Copper. Bronze. Polyester powder coated. Special finishes on request. Consult manufacturer for options. |
Operation | Fully automatic. Security mode with controlled access. |
Internal height | 3000 mm+. Available in 1 mm increments. |
Clear opening | 1000 mm+. External, available in 1 mm increments. To comply with Access to and use of buildings: Approved Document M. (Internal - 800 mm+). |
Door locking | Manual. Automatic. |
OptionsGlazing options. | Clear. Low iron. Coloured. Fritted. Ballistic. |
Canopy | Not required. 50 mm +. Available in 1 mm increments Please contact Bauporte for minimum heights if lighting or hot air units are required. |
Glazing | 18 mm glass. |
Safety | Designed, manufactured and installed to EN 16005. |
Power supply | Not required. 230 V/50 Hz. Automatic versions only. |
Drive unit | Underfloor drive unit. Full length of doorset. Overhead drive unit. Full length of doorset. |
Door frame | Stainless steel. |
Door leaf | Stainless steel structure with clear 12 mm safety glass. |
